Yaesu FT-7900R/E - PANEL Unit

G-5
Parts List
PANEL Unit
FT-7900R/E Technical Supplement
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
R 2060 CHIP RES. 10 1/10W 5% RMC1/10T 100J J24205100 1- B c3
R 2061 CHIP RES. 10 1/10W 5% RMC1/10T 100J J24205100 1- B b2
R 2062 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B c2
R 2063 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B c2
R 2064 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B c2
R 2065 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B c2
R 2066 CHIP RES. 390 1/16W 5% RMC1/16S 391JTH J24189020 1- B b2
R 2067 CHIP RES. 270 1/16W 5% RMC1/16S 271JTH J24189018 1- B c2
R 2068 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1- B d2
R 2069 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 1- B b2
R 2070 CHIP RES. 82 1/16W 5% RMC1/16S 820JTH J24189012 1- B b2
R 2071 CHIP RES. 82 1/16W 5% RMC1/16S 820JTH J24189012 1- B b1
R 2072 CHIP RES. 56k 1/16W 5% RMC1/16S 563JTH J24189046 1- B d2
R 2073 CHIP RES. 820 1/16W 5% RMC1/16S 821JTH J24189024 1- B e2
R 2074 CHIP RES. 47 1/16W 5% RMC1/16S 470JTH J24189009 1- B e2
R 2075 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B d2
R 2077 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B b2
R 2078 CHIP RES. 2.2M 1/16W 5% RMC1/16S 225JTH J24189065 1- B b2
R 2079 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b2
R 2080 CHIP RES. 15k 1/16W 5% RMC1/16S 153JTH J24189039 1- B b2
R 2081 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B b2
R 2082 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B b2
R 2083 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B b2
R 2084 CHIP RES. 150k 1/16W 5% RMC1/16S 154JTH J24189051 AUS 1- B b2
R 2084 CHIP RES. 150k 1/16W 5% RMC1/16S 154JTH J24189051 EXP 1- B b2
R 2084 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 USA 1- B b2
R 2085 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b2
R 2086 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- B b2
R 2087 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B b2
R 2088 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B a2
R 2089 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B b3
R 2090 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B f2
R 2091 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B f2
R 2092 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B f2
R 2093 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B2
R 2094 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A B2
R 2095 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B2
R 2096 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B2
R 2097 CHIP RES. 22 1/16W 5% RMC1/16S 220JTH J24189005 1- B e3
R 2098 CHIP RES. 22 1/16W 5% RMC1/16S 220JTH J24189005 1- B e2
R 2099 CHIP RES. 390 1/16W 5% RMC1/16S 391JTH J24189020 1- B c2
R 2100 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B g1
R 2101 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A B2
R 2102 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B a1
R 2103 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B a2
R 2104 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 W/O CE 8- B a2
S 2014 TACT SWITCH SKQMAL N5090105 1- A H1
S 2014 TACT SWITCH SKQMBBE010 N5090164 99- A H1
VR2001 POT. RK09D1130C2P 10KB J60800268 1- A A1
VR2002 POT. RK09D1130C2P 10KB J60800268 1- A A2
X 2001 XTAL CSA-310 3.6864MHz 3.6864MHZ H0102988 1- B f2
LCD HOLDER RA0540800 1-
INTER CONNECTOR RA0540900 1-
LIGHT GUIDE (LCD) RA0540700 1-
DIFFUSER SHEET RA0551800 1-
REFLECTOR SHEET RA0551900 1-
LCD SPACER RA0552200 1-
