Yaesu FT2DR Instruction Manual

5
APRS
®
initial settings
4 Turn the DIAL to select “MANUAL”
5 Press
The GPS clock will be set to MANUAL and the set mode
will be cancelled.
Tips
• You cannot connect a PC to operate the I-GATE and digipeater.
• The unit of the APRS data can be changed using the [APRS] →
[11 APRS UNIT] setting.
y Setting the position information (datum: WGS-84)
Enter the position information of your own station manually.
1 Press the key for one second or longer
The Set Mode Menu will appear.
2 Touch [APRS]
3 Turn the DIAL to select [24 MY POSITION] and touch it
on the display
The screen for selecting the setting method of the
position information will be displayed

Yaesu FT2DR Specifications

General

Frequency Range	144-148 MHz, 430-450 MHz
GPS	Yes
Waterproof Rating	IPX5
Bluetooth	Yes
Power Output	5 W
Modes	FM, C4FM
Weight	282 g
Operating Voltage	7.4V DC
Battery	7.4 V, 2200 mAh Li-Ion
