Table 1. Instruments and Controls (See Figure 5) (Continued)
Item
No.
Item Function
d Slow Speed Button The turtle button or slow speed mode enables the truck to operate at a
slower limited top speed.
This function is available in handle regions A, B, and C. Reference Figure 8
For operation in regions A and C, select and hold the turtle button then
rotate the speed/direction control in the direction of desire travel. Releasing
the turtle button will exit slow speed mode and reapply the brake. If the con-
trol handle is position to region B while the turtle button is held, the truck will
continue in slow speed mode.
If the turtle button is released, the truck will remain in slow speed mode until
speed/direction control returns to or passes through neutral.
Speed limiting operation is available in region B, from rest to travel, by
selection and release of the turtle button. Upon selection, the truck's display
will post TURTLE and the audible alarm will sound once. The truck will oper-
ate in slow speed mode. To exit region B slow speed mode, position the
control handle to region A or C, or select the turtle button. When slow speed
mode exit occurs by turtle button selection, the audible alarm will sound
twice and TURTLE will no longer post on the truck display.
Full traction performance is now available.
Model Description
21

Yale MPB045VG Specifications

General

Model	MPB045VG
Category	Forklifts
Power Source	Electric
Load Capacity	4500 lbs
Battery Voltage	24V
Battery Capacity	375 Ah
