Yale MPB045VG User Manual

1. BATTERY CHARGER
Figure 13. On-Board Charger
LED Status Display
The charger has five colored LED's located on the top of
the charger. The LED's are used to indicate the status of
the charger during operation. The order of the LED's may
vary with models, but they are labeled to identify their func-
tion. See Figure 14 and Table 3.
Maintenance
60

Yale MPB045VG Specifications

General

Model	MPB045VG
Category	Forklifts
Power Source	Electric
Load Capacity	4500 lbs
Battery Voltage	24V
Battery Capacity	375 Ah
