Table 3. Charger LED's
Indicator Port Color Function
Power On PWR Red Illuminates continuously when
AC power is present.
Abnormal Shutdown SDN Red Flashes if abnormal shutdown
has occurred.
Detection Error DET Red Illuminates continuously when
battery is not connect to
charger or battery voltage is
less than 2V.
Charging CHG Yellow Charge status indicator -
flashes during charging cycle.
Charged CHD Green Illuminates continuously when
battery is fully charged.
