Table 1. Instruments and Controls (See Figure 5) (Continued)
Item
No.
Item Function
8 Moveable Load Backrest with Load
Retention Strap
The moveable load backrest allows the operator to handle multiple pallets
with a single fork set-up. The quick latch and pivot arms make it easy to
change the position of the backrest when pallet types change.
Extend the movable load backrest when moving shorter pallets. To extend
the movable load backrest, lift the quick latch in the center of the backrest
and pull toward the forks.
The single seatbelt style, ratcheting and locking, load retention strap
secures the load.
Model Description
33
