Table 4. Battery Chart for DPI Gen III Chargers Only
Mfg Part Voltage Capacity
20HR/
RC@25A
(AmpHrs)
Application Batt Type DPI Gen III
Mode
US - Battery
Lead Acid
Batteries
US1800 24 208 Deep Cycle HV Flooded 2
AGM2224 24 224 Deep Cycle Absorbent Glass
Mat
4
Changing Mode Setting (DPI Accusense Gen
III Models with Jumper Ports)
NOTE: Mode settings can be checked by connecting
the battery charger to a 120V AC power source and
watching the LED display. The LED display will flash
once if the mode is set to Mode 1, twice if set to Mode
2, three times if set to Mode 3, and four times if the
charger is set to Mode 4. If the LEDs do not flash
when initially connected to power, refer to Trouble-
shooting (DPI Chargers) in this section.
Modes are set by the position of the jumpers on the
jumper port. Accessing the jumper port requires re-
moval of a plate on the front of the battery charger on
DPI Gen III chargers.
1. Remove the screws used to retain the jumper port
cover to the charger and remove the cover.
2. Locate the jumpers on the port.
3. Arrange the jumpers in the proper configuration
for your battery type.
4. Replace the cover on the charger and install the
mounting screws.
Accusense Gen III with Dip Switches
Battery Charger (Accusense by DPI
®
)
2200 YRM 1007
40
