Table 8. (See Figure 18 through Figure 27) (Continued)
Item
No.
Item
8 Hr/
1 Day
250 Hr/
6 Mo
500 Hr/
6 Mo
1000
Hr/
6 Mo
2000 Hr/
1 Yr
4000 Hr/
2 Yr
Procedure or
Quantity
Specification
MAST
Integral Sideshift
Carriage Lower
Mounting Hook
X Check for Wear and
Clearance.
See NOTE
2 and
NOTE 5.
0.76 mm (0.03 in.)
Minimum
Wear Limit.
TILT CYLINDER ENDS L 4 Fittings Multipurpose Grease
See NOTE 9.
BRAKE MASTER CYL-
INDER ROD END PIN
L SAE 10W-30
API SM
ILSAC GF4
SAE J2362
MANUAL HYDRAULIC
HAND LEVERS
L SAE 10W-30
API SM
ILSAC GF4
SAE J2362
26 BRAKE FLUID CIL X C 0.25 liter (0.53 pt) SAE J-1703 (DOT 3)
11 STEERING AXLE TIE
ROD ENDS
L 4 Fittings Multipurpose Grease
See NOTE 9.
11 STEERING AXLE
King Pins
L 2 Fittings Multipurpose Grease
See NOTE 9.
X = Check C = Change L = Lubricate CIL = Check indicator light during operation
Maintenance Schedule
137
