Table 2. Display Switch Cluster – Right-Side Display Inputs (See Figure 6) (Continued)
Item
No.
Item Function
9 Scroll Down This button is used for the following functions:
• Decreasing
the value of a selected operating function
• Scrolling downward through a list of possible menu selections
10 #4 Button The Scroll Down and #4 Button share the same space on the Display Switch Cluster.
When an operator or supervisor is in the main menu for entering and administering
passwords, the Scroll Down function is disabled and the button is enabled to enter the
number 4 for password purposes.
11 Scroll Up
This button is used for the following functions:
• Increasing
the value of a selected operating function
• Scrolling upward through a list of possible menu selections
12 #5 Button The Scroll Up and #5 Button share the same space on the Display Switch Cluster.
When an operator or supervisor is in the main menu for entering and administering
passwords, the Scroll Up function is disabled and the button is enabled to enter the
number 5 for password purposes.
