Table 4. Operator Controls (See Figure 8) (Continued)
Item
No.
Item Function
6 Inching/Brake
Pedal
By varying the position of the inching/brake pedal, the operator can move the lift
truck slowly while
a high engine speed is used for lifting loads. Completely
depressing the pedal disengages the transmission and applies the service brakes.
The engine can be started when the inching/brake pedal is fully depressed and
Direction Control Lever is in neutral.
7 Brake Pedal
This pedal, controlled by the operator's right foot, controls the application of the
service brakes.
Model Description
44
