NOTE: SWIVEL SEAT IS AN OPTIONAL FEATURE.
1. BACKREST ANGLE ADJUSTMENT LEVER
2. SWIVEL ADJUSTMENT
3. OPERATOR WEIGHT ADJUSTMENT
4. FORWARD/BACKWARD ADJUSTMENT HANDLE
5. SEAT BELT
Figure 24. Swivel Seat Controls
Engine Compartment
Check for the presence of any combustible material such as
paper, leaves etc. Remove any combustible materials.
Paper Application
Vehicles used in paper applications require regular inspec-
tion and cleaning to minimize the risk of fire. This should be
done at least once every 8 hours or more frequently depend-
ing upon operating environment. The paper application will
help limit the contact of paper or tissue scraps to hot surfaces
under the hood, but frequent maintenance is required.
WARNING
Engine and exhaust system components are hot to the
touch. Be sure lift truck components are cool before
starting inspection and cleaning, or personal injury may
occur.
Ensure the truck engine cools properly by allowing it to idle
for several minutes. Shutting the truck down while hot will not
allow the engine to cool quickly due to the loss of coolant
circulation. The heat trapped under the hood may actually
increase the engine temperature because of no heat transfer
through the radiator.
Maintenance
142
