1. TILT LEVER 2. GAS CYLINDER
Figure 25. Steering Column Gas Cylinder and Tilt Lever
Hydraulic System Oil
WARNING
At operating temperature the hydraulic oil is HOT. Do not
permit the hot oil to touch the skin and cause a burn.
CAUTION
Do not permit dirt to enter the hydraulic system when the
oil level is checked or the filter is changed.
Never operate the hydraulic pump without oil in the
hydraulic system. The operation of the hydraulic pump
without oil will damage the pump.
Check the hydraulic system for leaks and damaged or loose
components. Heavy-duty or high-temperature operations
can require more frequent checks.
Maintenance
145
