Nameplate
WARNING
DO NOT add to or modify the lift truck. Any modification
that affects the safe operation of the truck cannot be
undertaken without the written authorization of Yale Cor-
poration.
Any change to the lift truck, the tires, or its equipment
can change the lifting capacity. The lift truck must be
rated as equipped and the Nameplate must show the new
capacity rating.
The capacity is specified in kilograms (kg) and pounds (lb).
The capacity is the maximum load that the lift truck can han-
dle for the load condition shown on the Nameplate.
The maximum capacity for the lift truck, at full load height,
must be shown on the Nameplate. Special capacities with the
load height reduced or with optional load centers, may also
be shown on the Nameplate.
NOTE: The image in Figure 3 is a sample only. Reference
the actual nameplate installed on the truck for actual truck
specifications.
The lift truck serial number code is on the Nameplate. The
serial number code is also stamped on the right-hand side of
the lift truck frame, under the floorplate.
When a lift truck is shipped incomplete from the factory, the
Nameplate is covered by an INCOMPLETE label as shown
in Figure 3. If the equipment on the truck is changed, the
Nameplate is covered by a NOTICE label as shown in Fig-
ure 3. If your lift truck has either of these labels, do not oper-
ate the lift truck. Contact your dealer for Yale lift trucks to
obtain a complete and correct Nameplate.
Model Description
14
