The operator must never leave a lift truck in a condition so
that it can cause damage and injury. When the lift truck is
loaded on the transport, do the following operations:
1. Apply the parking brake.
2. If the mast is mounted on the lift truck, fully lower the forks
or carriage. Tilt the mast FORWARD until the tips of the forks
touch the surface.
3. Put the direction control lever for the powershift transmis-
sion in NEUTRAL (N). If the lift truck has a manual transmis-
sion, leave the gears of the transmission engaged. DO NOT
leave a manual transmission in NEUTRAL (N).
4. Turn the key switch to OFF to stop the engine, if truck is
equipped with a key switch, or press the Power ON/OFF but-
ton, if truck is equipped with a keyless option. Check that all
switches and accessories are turned OFF.
5. Put blocks in front and back of the lift truck tires to prevent
any movement of the lift truck. Make sure the blocks are
attached to the load surface.
If the lift truck is equipped with an LPG fuel system and is not
in active use, close the fuel valve at the tank. If the lift truck
is going to be left overnight or longer, the truck must be
parked outside or the LPG tank must be removed and stored
outside.
If the lift truck is transported in severe weather or any other
condition that can damage the lift truck, cover the lift truck.
Make sure the protective cover is designed for the application
and is securely fastened.
Unloading
If components normally attached to the lift truck were
removed for transport, see the Service Manual for installa-
tion procedures.
1. If used, remove any protective cover.
2. Make sure the parking brake is applied.
3. Disconnect the straps or chains.
4. Remove the wheel blocks.
5. Check that all switches and accessories are turned OFF.
6. Unload the lift truck.
Maintenance
199
