Seat Adjustment for Operator Weight
CAUTION
A major cause for high Whole Body Vibration is caused
by the operator not adjusting the seat to his/her weight.
NOTE: It is important to adjust the weight setting for each
operator.
NOTE: The seat is designed for a maximum weight of 135 kg
(298 lb).
• The target is for the "ride indicator" to fall between the
arrows when the operator sits upright in the seat with the
feet positioned on the pedals. This ensures that the oper-
ator is set at the midpoint of the 80 mm (3.5 in.) suspen-
sion.
• The handle can be turned as shown to increase or
decrease the weight resistance, pull handle out before
turning. As the handle is turned the "stiffness" of the sus-
pension can be felt to increase or decrease depending on
which way the handle is turned.
Operating Procedures
78
