Flip Mode
In Flip mode, the faders, Encoders, and [ON] buttons can be used to control sends, as
shown in the following table.
1 Press the FADER MODE [FADER] or [AUX] button.
The FADER MODE [FADER] and [AUX] button indicators flash alternately, and both the
ENCODER MODE [PAN] (PAN) and [AUX] (SEND LEVEL) button indicators light up.
The SELECT ASSIGN section of the display shows “FLIP.”
2 Use the AUX SELECT [AUX 1]–[AUX 5] (SEND A–E) buttons to select the
sends.
The button indicator of the selected send lights up.
3 Use the faders, Encoders, and [ON] buttons to control the currently selected
send.
For stereo aux input channels (i.e., channels with two send panpots), use the ENCODER
MODE [PAN] (PAN) button to toggle between the left and right panpots, and pan with the
Encoder. When the left panpot is active, the ENCODER MODE [PAN] (PAN) button indi-
cator is lit continuously. When the right panpot is active, the ENCODER MODE [PAN]
(PAN) button indicator flashes.
Control Normal mode Flip mode
Fader Channel level Send level
Encoder Channel pan/send level Send pan
Encoder push-switches
Encoder mode is Pan, inactive
Encoder mode is Send level, Send pre/post
Send pre/post
[ON] button Channel mute Send mute
