Initial Output Patch Settings 249
02R96 Version 2—Owner’s Manual
Initial Output Patch Settings
Slot Outputs Omni Outs
Direct Outs
# Source # Source
SLOT1-01 BUS1 SLOT3-01 BUS1
SLOT1-02 BUS2 SLOT3-02 BUS2
SLOT1-03 BUS3 SLOT3-03 BUS3
SLOT1-04 BUS4 SLOT3-04 BUS4
SLOT1-05 BUS5 SLOT3-05 BUS5
SLOT1-06 BUS6 SLOT3-06 BUS6
SLOT1-07 BUS7 SLOT3-07 BUS7
SLOT1-08 BUS8 SLOT3-08 BUS8
SLOT1-09 BUS1 SLOT3-09 BUS1
SLOT1-10 BUS2 SLOT3-10 BUS2
SLOT1-11 BUS3 SLOT3-11 BUS3
SLOT1-12 BUS4 SLOT3-12 BUS4
SLOT1-13 BUS5 SLOT3-13 BUS5
SLOT1-14 BUS6 SLOT3-14 BUS6
SLOT1-15 BUS7 SLOT3-15 BUS7
SLOT1-16 BUS8 SLOT3-16 BUS8
SLOT2-01 BUS1 SLOT4-01 BUS1
SLOT2-02 BUS2 SLOT4-02 BUS2
SLOT2-03 BUS3 SLOT4-03 BUS3
SLOT2-04 BUS4 SLOT4-04 BUS4
SLOT2-05 BUS5 SLOT4-05 BUS5
SLOT2-06 BUS6 SLOT4-06 BUS6
SLOT2-07 BUS7 SLOT4-07 BUS7
SLOT2-08 BUS8 SLOT4-08 BUS8
SLOT2-09 BUS1 SLOT4-09 BUS1
SLOT2-10 BUS2 SLOT4-10 BUS2
SLOT2-11 BUS3 SLOT4-11 BUS3
SLOT2-12 BUS4 SLOT4-12 BUS4
SLOT2-13 BUS5 SLOT4-13 BUS5
SLOT2-14 BUS6 SLOT4-14 BUS6
SLOT2-15 BUS7 SLOT4-15 BUS7
SLOT2-16 BUS8 SLOT4-16 BUS8
# Source
1 AUX1
2 AUX2
3 AUX3
4 AUX4
5 AUX5
6 AUX6
7 AUX7
8 AUX8
# Destination # Destination
1 SLOT1-01 29 SLOT4-05
2 SLOT1-02 30 SLOT4-06
3 SLOT1-03 31 SLOT4-07
4 SLOT1-04 32 SLOT4-08
5 SLOT1-05 33 NONE
6 SLOT1-06 34 NONE
7 SLOT1-07 35 NONE
8 SLOT1-08 36 NONE
9 SLOT2-01 37 NONE
10 SLOT2-02 38 NONE
11 SLOT2-03 39 NONE
12 SLOT2-04 40 NONE
13 SLOT2-05 41 NONE
14 SLOT2-06 42 NONE
15 SLOT2-07 43 NONE
16 SLOT2-08 44 NONE
17 SLOT3-01 45 NONE
18 SLOT3-02 46 NONE
19 SLOT3-03 47 NONE
20 SLOT3-04 48 NONE
21 SLOT3-05 49 NONE
22 SLOT3-06 50 NONE
23 SLOT3-07 51 NONE
24 SLOT3-08 52 NONE
25 SLOT4-01 53 NONE
26 SLOT4-02 54 NONE
27 SLOT4-03 55 NONE
28 SLOT4-04 56 NONE
