52 Chapter 3—Operating Basics
02R96 Version 2—Owner’s Manual
Assignable Encoder Mode Parameter List
# Parameter Encoder Operation Push Switch Operation
1 No Assign ——
2 Attenuator Attenuator —
3 Input Patch Input Channel patch Confirm or execute patch selection.
4 Insert In Patch Insert In patch Confirm or execute patch selection.
5 Insert Out Patch Insert Out patch Confirm or execute patch selection.
6 Direct Out Direct Out patch Confirm or execute patch selection.
7 Phase Phase: normal/reverse —
8 Insert On Insert on/off —
9 Aux pre/post Aux pre/post —
10 Delay On Delay on/off —
11 Delay Time Delay Time —
12 Delay FB.Gain Delay FB.Gain —
13 Delay Mix Delay Mix —
14 EQ On EQ on/off —
15 EQ Type EQ Type —
16 EQ Low Q EQ Low Q —
17 EQ Low F EQ Low Frequency —
18 EQ Low G EQ Low Gain —
19 EQ Low-Mid Q EQ Low-Mid Q —
20 EQ Low-Mid F EQ Low-Mid Frequency —
21 EQ Low-Mid G EQ Low-Mid Gain —
22 EQ High-Mid Q EQ High-Mid Q —
23 EQ High-Mid F EQ High-Mid Frequency —
24 EQ High-Mid G EQ High-Mid Gain —
25 EQ High Q EQ High Q —
26 EQ High F EQ High Frequency —
27 EQ High G EQ High Gain —
28 Gate On Gate on/off —
29 Gate Threshold Gate Threshold —
30 Gate Range Gate Range —
31 Gate Attack Gate Attack —
32 Gate Decay Gate Decay —
33 Gate Hold Gate Hold —
34 Comp On Comp on/off —
35 Comp Threshold Comp Threshold —
36 Comp Ratio Comp Ratio —
37 Comp Attack Comp Attack —
38 Comp Release Comp Release —
39 Comp Out Gain Comp Out Gain —
40 Comp Knee/Width Comp Knee/Width —
41 Surr L/R Pan Surround L/R Pan —
42 Surr F/R Pan Surround F/R Pan —
43 Surr Front DIV Surround Front DIV —
44 Surr Rear DIV Surround Rear DIV —
45 Surr. LFE Level Surround LFE level —
46 Surr. Pan Wheel Surround Pan Wheel —
47 Scene Fade Time Scene Fade Time —
48 Alt Layer Alt Layer —
