CYLINDER HEAD
5-25
EAS24100
CYLINDER HEAD
Removing the cylinder head
Order Job/Parts to remove Q’ty Remarks
Engine Refer to “ENGINE REMOVAL” on page 5-3.
Intake camshaft Refer to “CAMSHAFTS” on page 5-13.
Exhaust camshaft Refer to “CAMSHAFTS” on page 5-13.
1 Coolant temperature sensor 1
2 Cylinder head 1
3 Cylinder head gasket 1
4Dowel pin 2
For installation, reverse the removal proce-
dure.
To Next Page
