Instrument operation
58
Setting screen
The setting screen can be used to change the
settings of the multi-function display unit.
Time setting screen
Perform settings related to the time.
To set the time:
(1) Select a 12 hour display or 24 hour dis-
play.
(2) Tap “ ” or “ ” to adjust GMT off-
set.
(3) Select to enable or disable daylight sav-
ing time.
Depth alarm setting screen
The water depth for the depth alarm can be
set.
1 Slider control
To adjust the water depth setting:
(1) Move the slider control left or right.
TIP:
 The water depth can also be adjusted by
tapping the “ ” or “ ” button.
 If the water depth is set to 0.0 m (0.0 ft), the
depth alarm will not operate.
(2) Tap “Back” to complete the setting.
Unit setting screen
The display units for the multi-function dis-
play unit can be changed.
Item Function
Time Displays the time setting
screen.
Depth Displays the depth alarm
setting screen.
Unit Displays the unit setting
screen.
Brightness Displays the brightness
setting screen.
Wellness Displays the maintenance
setting screen.
Language Displays the language set-
ting screen.
Tuner Region Displays the tuner region
setting screen.
Menu
Tuner Region
Time Depth
Unit Brightness
Wellness Language
Back
Time
12-Hour:
GMT Offset:
Daylight Saving Time: Disabled
-4
24-Hour:
Back
Set Depth Alarm
5.0
Ft
1
