Operation and handling requirements
92
Engine compartment
1 Engine compartment drain plug
To drain the bilge water from the hull:
Remove the hull drain plug at the stern to
drain the water. Check the condition of the O-
ring on the hull drain plug, and then securely
install the drain plug.
1 Hull drain plug
Draining the bilge water on water
This model is equipped with a self-draining
deck and bilge pump to drain the bilge water
on water.
Self-draining deck
Most water that enters the deck area drains
automatically out the stern through the large
drain hole in the deck.
A one-way check valve in the drain prevents
water from traveling back to the deck while
the boat is moored or moving in reverse.
Bilge pump
Your boat is equipped with a drainage sys-
tem that channels water that enters the boat
from the storage compartments to the bilge
under the engine compartment.
When the “Bilge” button is tapped, the bilge
pump will operate.
1 “Bilge” button
1
Bilge Blower
FUEL
%
100
x1000 rpm
9
19
START
V
13.0
SE
