Yamaha 2A - Page 60

3-25
E
N
EMU00962
PROCEDURE FOR TILTING UP
1) Tighten the air vent screw.
If the fuel connector is provided on
the motor, remove the fuel line con-
nection from the motor.
2) Put the fuel cock lever in the closed
position.
222012
315021*
3
CLOSE
2 3
5
CLOSE
315016
3) Place the gear shift lever in Neutral
and face the motor forward.
6A1-9-1L 3 4/20/01 11:59 AM Page 26
