3-26
E
403022
403016
403022*
403031
4) Hold the rear of the top cowling with
one hand and fully tilt the engine up.
2
5) Push the tilt support knob into the
clamp bracket.
3/5
5) The tilt support bar turns to the
locked position automatically.
EMU00298
PROCEDURE FOR TILTING DOWN
1) Slightly tilt up the engine.
2
2) Pull out the tilt support knob, then tilt
down the engine.
3/5
2) Tilt down the engine pulling up the
lever of the tilt support bar.
2
3/5
