– 21 –
CHK
ADJ
T
R
.
.
23 Nm (2.3 m
•
kg, 17 ft
•
Ib)
T
R
.
.
23 Nm (2.3 m
•
kg, 17 ft
•
Ib)
3
(4)
(4)
(4)
9
8
2
5
1
4
7
6
Order Job/Part Q’ty Remarks
5 Battery 1
6 Carburetor joint clamp screw 1 Loosen.
7 Crankcase breather hose 1 Disconnect.
8 Air filter case 1
9 Rear fender 1
For installation, reverse the removal pro-
cedure.
SEAT, CARRIERS AND FENDERS
