– 20 –
CHK
ADJ
SEAT, CARRIERS AND FENDERS
REAR CARRIER AND REAR FENDER
T
R
.
.
23 Nm (2.3 m
•
kg, 17 ft
•
Ib)
T
R
.
.
23 Nm (2.3 m
•
kg, 17 ft
•
Ib)
3
(4)
(4)
(4)
9
8
2
5
1
4
7
6
Order Job/Part Q’ty Remarks
Removing the rear carrier and rear
fender
Remove the parts in the order listed.
Seat/center cover Refer to “SEAT, FRONT CARRIER,
FRONT BUMPER AND CENTER
COVER”.
Front grill assembly/front fender Refer to “FRONT GRILL ASSEMBLY
AND FRONT FENDER”.
1 Tail/brake light connector 3 Disconnect.
2 Tail/brake light 1
3 Rear carrier 1
4 Battery lead 2 Disconnect.
CAUTION:
First disconnect the negative lead,
then disconnect the positive lead.
