– 28 –
– +
ELEC
LIGHTING SYSTEM
EBS01069
YES
NO
5. Wiring
• Check the entire lighting system’s wiring.
Refer to “WIRING DIAGRAM”.
• Is the lighting system’s wiring properly
connected and without defects?
Check the condition
of each of the lighting
system’s circuits.
Refer to “LIGHTING
SYSTEM” in chapter
7 (Manual No.: 3FA-
ME1).
Properly connect or
repair the lighting
system’s wiring.
