Basic components
8
40VETO, 40YETO, 50HEDO, 50HETO
EMU25802
Fuel tank
If your model was equipped with a portable
fuel tank, its function is as follows.
WARNING
EWM00020
The fuel tank supplied with this engine is
its dedicated fuel reservoir and must not
be used as a fuel storage container. Com-
mercial users should conform to relevant
licensing or approval authority regula-
tions.
113
14 15 16
17
2
3
4
6
5
7
8
4
9
10
11
12
ZMU04548
1. Oil tank filler cap
2. Warning indicator(s)
3. Battery cable
4. Anode(s)
5. Propeller
6. Cooling water inlet
7. Trim tab (anode)
8. Anti-cavitation plate
9. Trim rod
10. Clamp bracket
11. Tilt support lever
12. Top cowling
13. Remote control box (side mount type)*
14. Trim meter*
15. Tachometer*
16. Digital tachometer*
17. Fuel tank*
