Operation
38
also affected by variables such as the load in
the boat, sea conditions, and running speed.
WARNING
EWM00740
Excessive trim for the operating condi-
tions (either trim up or trim down) can
cause boat instability and can make
steering the boat more difficult. This in-
creases the possibility of an accident. If
the boat begins to feel unstable or is hard
to steer, slow down and/or readjust the
trim angle.
EMU27871
Adjusting trim angle for manual tilt
models
There are 4 or 5 holes provided in the clamp
bracket to adjust the outboard motor trim an-
gle.
1. Stop the engine.
2. Remove the trim rod from the clamp
bracket while slightly tilting the outboard
motor up.
3. Reposition the rod in the desired hole.
To raise the bow (“trim-out”), move the rod
away from the transom.
To lower the bow (“trim-in”), move the rod to-
ward the transom.
Make test runs with the trim set to different
angles to find the position that works best for
your boat and operating conditions.
WARNING
EWM00400
●
Stop the engine before adjusting the
trim angle.
●
Use care to avoid being pinched when
1. Trim operating angle
ZMU03109
1
1. Trim rod
1. Trim rod
1
ZMU03402
