6-5
E
LOWR
DISASSEMBLY
7) Propeller shaft
(For 50GETO, C60ER, C60TR/60FET
(Oceania), C75TR, 90AEHD, 90AED,
C90TR/90AET)
1 Clutch dog
2 Cross pin
3 Cross pin ring
7) Propeller shaft
(Except for 50GETO, C60ER, C60TR/
60FET (Oceania), C75TR, 90AEHD,
90AED, C90TR/90AET)
1 Clutch dog
2 Cross pin
3 Cross pin ring
8) Shift slide
(Except for 50GETO, C60ER, C60TR/
60FET (Oceania), C75TR, 90AEHD,
90AED, C90TR/90AET)
Using a slotted screwdriver, remove
the shift slide balls 1 from the neu-
tral position and pull out the shift
slide 2 and shifter 3.
9) Reverse gear and bearing
Å For USA and Canada
ı Except for USA and Canada
Slide hammer set:
YB-6096.................................. 1
Stopper guide plate:
90890-06501........................... 2
Bearing puller:
90890-06535........................... 3
Stopper guide stand:
90890-06538........................... 4
Å
ı
