Yamaha CD-C600 - Parts List: Operation PCBs

56
Ref No. Part No. Description Markets Ref No. Part No. Description Markets
CD-C600
CD-C600
D805-810 VS997800 DIODE 1T2
D811 VG443200 DIODE.ZENR MTZJ30A 30V
D812-813 VT332900 DIODE 1SS355
D814 VG438600 DIODE.ZENR MTZJ7.5B 7.5V
D815 VT332900 DIODE 1SS355
D816 VG438800 DIODE.ZENR MTZJ8.2A 8.2V
D817-819 VT332900 DIODE 1SS355
D820-821 VV220700 DIODE.SHOT RB501V-40
D822 VG438000 DIODE.ZENR MTZJ6.2B 6.2V
D851 VR253700 DIODE.BRG S1NB20 1A 200V
D852 VS997800 DIODE 1T2 RL
D853 VU992300 DIODE.ZENR MAZ8047GHL 4.9V
D854 VT332900 DIODE 1SS355 RL
D855-856 VT332900 DIODE 1SS355
⚠
F801 KB000710 FUSE 500mA 250V
IC501 V2363400 PHOT.INTR ON1024
IC502 XK583A00 IC TA7291P
IC503 XF947A00 IC LA6510
IC601-602 XA987A00 IC NJM2068D-D
IC701 X2656A00 IC TC7SH08F AND
IC801-802 X4928A00 IC KIA7805API 5V
IC803 X7973A00 IC KIA79M05PI-U
IC851 X9117A00 IC R1154N033B-TR-F
PJ601 VV411100 JACK.PIN 2P
Q601-604 VZ725900 TR 2SD1938F S,T
Q701-702 VV556400 TR 2SC2412K Q,R,S
Q703-704 VV655000 TR.DGT DTA114EKA
Q705 VV655400 TR.DGT DTC114EKA
Q706 VV556400 TR 2SC2412K Q,R,S
Q801 VP872600 TR 2SA1708 S,T
Q804 VS883400 TR 2SD2394 E,F
Q806 VV556500 TR 2SA1037K Q,R,S
Q851 VR043100 FET 2SK208 Y
Q852 VC938500 TR 2SC3852 RL
Q853 VC938500 TR 2SC3852
Q854 iC1815I0 TR 2SC1815 Y
R505-506 HV753100 R.CAR.FP 1Ω 1/4W
R509 HV756120 R.CAR.FP 1.2KΩ 1/4W
R801 HV756470 R.CAR.FP 4.7KΩ 1/4W
* R802 HL006470 R.MTL.OXD 4.7KΩ 1/2W
R805 V8071600 R.MTL.FLM 1KΩ 1W
⚠
R806 V8071300 R.MTL.FLM 470Ω 1W
R808 HV755330 R.CAR.FP 330Ω 1/4W
R813-814 HV755100 R.CAR.FP 100Ω 1/4W
R815-816 HV753470 R.CAR.FP 4.7Ω 1/4W
⚠
RY801 WK441000 RELAY DC ALKT329 M01
ST701-703 V4040500 SCR.TERM M3
ST801-802 V4040500 SCR.TERM M3 RL
SW501-502 Vi294000 SW.LEVER SSCF21
SW701-713 V4757100 SW.TACT EVQ11A
⚠
SW801 V8377400 SW.POWER SY16-52-4
⚠
* SW802 WH813600 VOLT.SELCT VSA-14-3 RL
⚠
* T801 YA771A00 TRANS.PWR UC
⚠
* T801 YA772A00 TRANS.PWR RL
⚠
* T801 YA775A00 TRANS.PWR A
⚠
* T801 YA774A00 TRANS.PWR G
⚠
* T851 YA879A00 TRANS.PWR UC
* T851 YA881A00 TRANS.PWR RL
* T851 YA880A00 TRANS.PWR AG
⚠
* TE801 WR903000 INLET.AC 2P HJC-036AP UC
⚠
* TE801 WS090800 INLET.AC 2P HJC-036P RAGL
⚠
TH801-802 VU847300 POSISTOR RUE185 1.85A 30V
TH803 VV457600 SW.POLY RUE090 0.90A 30V
U701 WK918500 L.DTCT GP1UE271RKVF
* V701 WR861000 FL.DSPLY 14-ST-68GINK
* WS050700 SHEET.FL 118x20.5
V3422300 SPACER FL-WIDE
WE983600 SCR.BND.HD 3x8 MFZN2B3
P.C.B. OPERATION
✻ New Parts ✻ New Parts
