CS2X
25
T23. MODULATION WHEEL TEST
23 MW xxx
000
(xxx: current MODULATION wheel value)
According to the target value displayed on the LCD,
slowly rotate the MODULATION wheel.
Check that the value changes from 00 to 127 and then
back to 00 (in other words: from bottom to top and then
back to bottom).
23 MW xxx
yyy
(xxx: current MODULATION wheel value
yyy: next target value)
DISPLAY OF THE RESULTS
OK 23 MW xxx
OK
NG (No change in display message)
TEST END
The test ends after displaying the result.
T24. FOOT VOLUME TEST
24 F.V xxx
000
(xxx: current FOOT VOLUME value)
According to the target value displayed on the LCD,
gently press the FOOT VOLUME pedal.
Check that value changes from 00 to 127 then back to 00
(in other words: from the raised position to the lowered
position then back to the raised position).
24 F.V xxx
yyy
(xxx: current FOOT VOLUME value
yyy: next target value)
DISPLAY OF THE RESULTS
OK 24 F.V xxx
OK
NG (No change in display message)
TEST END
The test ends after displaying the result.
T25. FOOT CONTROLLER TEST
25 F.C xxx
000
(xxx : current FOOT CONTROLLER value)
According to the target value displayed on the LCD,
gently press the FOOT CONTROLLER pedal.
Check that value changes from 00 to 127 then back to 00
(in other words: from the raised position to the lowered
position then back to the raised position).
25 F.C xxx
yyy
(xxx: current FOOT CONTROLLER value
yyy: next target value)
DISPLAY OF THE RESULTS
OK 25 F.C xxx
OK
NG (No change in display message)
TEST END
The test ends after displaying the result.
T26. FOOT SWITCH TEST
26 F.S off
on
Connect a FOOT SWITCH, press down and lift up.
Check that the indication on the LCD changes from off
to ON then back to off, and verify that the “OK” result is
displayed.
26 F.S xxx
yyy
(xxx: current FOOT SWITCH value
yyy : next target value)
DISPLAY OF THE RESULTS
OK 26 F.S off
OK
NG (No change in display message)
TEST END
The test ends after displaying the result.
To Next Page
