Yamaha CS2x Service Manual

CS2X
5
: New Parts
REF NO. PART NO. DESCRIPTION REMARKS QTY RANK
RANK : Japan only
C75 Electrolytic Cap. 470.00 25.0V 01
C76 Monolithic Ceramic Cap. F 0.1 25V Z 01
C77 Electrolytic Cap. (chip) 100 16V 01
C77 Electrolytic Cap. (chip) 100UF 16V 01
C78 Electrolytic Cap. 100.00 25.0V 01
C79 Mylar Capacitor (chip) 0.1 50V J 01
C80 Monolithic Ceramic Cap. F 0.1 25V Z 01
C81 Electrolytic Cap. (chip) 220 16V UUR1C2 01
C82 Electrolytic Cap. (chip) 47 16V 01
C82 Electrolytic Cap. (chip) 47UF 16V 01
C83 Monolithic Ceramic Cap. F 0.1 25V Z 01
C84 Monolithic Ceramic Cap. F 0.1 25V Z 01
C85 Electrolytic Cap. (chip) 47 16V 01
C85 Electrolytic Cap. (chip) 47UF 16V 01
C86 Electrolytic Cap. (chip) 10 16V 01
C86 Electrolytic Cap. (chip) 10UF 16V 01
C87 Monolithic Ceramic Cap. F 0.1 25V Z 01
C88 Electrolytic Cap. (chip) 10 16V 01
C88 Electrolytic Cap. (chip) 10UF 16V 01
C89 Monolithic Ceramic Cap. F 0.1 25V Z 01
-92 Monolithic Ceramic Cap. F 0.1 25V Z 01
C93 Electrolytic Cap. (chip) 10 16V 01
C93 Electrolytic Cap. (chip) 10UF 16V 01
C94 Monolithic Ceramic Cap. F 0.01 50V Z 01
C95 Monolithic Ceramic Cap. F 0.1 25V Z 01
C96 Electrolytic Cap. (chip) 10 16V 01
C96 Electrolytic Cap. (chip) 10UF 16V 01
C97 Monolithic Ceramic Cap. F 0.1 25V Z 01
C98 Electrolytic Cap. (chip) 10 16V 01
C98 Electrolytic Cap. (chip) 10UF 16V 01
C99 Monolithic Ceramic Cap. F 0.1 25V Z 01
C100 Electrolytic Cap. (chip) 10 16V 01
C100 Electrolytic Cap. (chip) 10UF 16V 01
C101 Monolithic Ceramic Cap. F 0.1 25V Z 01
C103 Monolithic Ceramic Cap. SL 47P 50V J 01
C104 Monolithic Ceramic Cap. F 0.1 25V Z 01
C105 Monolithic Ceramic Cap. F 0.1 25V Z 01
C106 Electrolytic Cap. (chip) 47 16V 01
C106 Electrolytic Cap. (chip) 47UF 16V 01
C107 Electrolytic Cap. (chip) 47 16V 01
C107 Electrolytic Cap. (chip) 47UF 16V 01
C108 Electrolytic Cap. (chip) 47 16V 01
C108 Electrolytic Cap. (chip) 47UF 16V 01
C109 Monolithic Ceramic Cap. F 0.1 25V Z 01
C110 Electrolytic Cap. (chip) 22 16V 01
C110 Electrolytic Cap. (chip) 22UF 16V 01
C111 Monolithic Ceramic Cap. F 0.1 25V Z 01
C112 Electrolytic Cap. (chip) 22 16V 01
C112 Electrolytic Cap. (chip) 22UF 16V 01
C113 Monolithic Ceramic Cap. B 2700P 50V K 01
C114 Monolithic Ceramic Cap. SL 220P 50V J 01
C115 Monolithic Ceramic Cap. B 6800P 50V K 01
C116 Monolithic Ceramic Cap. SL 100P 50V J 01
C117 Monolithic Ceramic Cap. SL 100P 50V J 01
C118 Monolithic Ceramic Cap. F 0.1 25V Z 01
C119 Monolithic Ceramic Cap. SL 47P 50V J 01
C120 Monolithic Ceramic Cap. B 2200P 50V K 01
C121 Monolithic Ceramic Cap. F 0.1 25V Z 01
C122 Monolithic Ceramic Cap. SL 100P 50V J 01
C123 Electrolytic Cap. (chip) 100 16V 01
C123 Electrolytic Cap. (chip) 100UF 16V 01
C124 Electrolytic Cap. (chip) 22 16V 01
C124 Electrolytic Cap. (chip) 22UF 16V 01
C125 Monolithic Ceramic Cap. B 2200P 50V K 01
C126 Electrolytic Cap. (chip) 220 16V UUR1C2 01
C127 Monolithic Ceramic Cap. B 1000P 50V K 01
C128 Monolithic Ceramic Cap. F 0.01 50V Z 01
C129 Electrolytic Cap. (chip) 22 16V 01
C129 Electrolytic Cap. (chip) 22UF 16V 01
C130 Monolithic Ceramic Cap. B 2700P 50V K 01
VH340500
UB245100
UF038100
UG038100
UR848100
VR331500
UB245100
UF138220
UF037470
UG037470
UB245100
UB245100
UF037470
UG037470
UF037100
UG037100
UB245100
UF037100
UG037100
UB245100
UB245100
UF037100
UG037100
UB044100
UB245100
UF037100
UG037100
UB245100
UF037100
UG037100
UB245100
UF037100
UG037100
UB245100
UB051470
UB245100
UB245100
UF037470
UG037470
UF037470
UG037470
UF037470
UG037470
UB245100
UF037220
UG037220
UB245100
UF037220
UG037220
UB013270
UB052220
UB013680
UB052100
UB052100
UB245100
UB051470
UB013220
UB245100
UB052100
UF038100
UG038100
UF037220
UG037220
UB013220
UF138220
UB013100
UB044100
UF037220
UG037220
UB013270




















































Yamaha CS2x Specifications

General

Polyphony	64 voices
Multitimbral Capacity	16 parts
LFO	2 LFOs per voice
Keyboard	61 keys
Velocity Sensitivity	Yes
Aftertouch	No
Control	Pitch bend, Modulation wheel
Weight	6.5 kg
Year Released	1998
Type	Synthesizer
Oscillators	AWM2
Filter	Resonant filter
Effects	Reverb, Chorus, Variation
Storage	Internal memory for patches
MIDI	In, Out, Thru
Outputs	Stereo output, Headphone output
Inputs	Sustain pedal, Foot controller
Memory	128 user voices
Connections	MIDI (In/Out/Thru), Foot Controller, Foot Switch
