Yamaha CS2x Service Manual

CS2X
6
*
*
: New Parts
REF NO. PART NO. DESCRIPTION REMARKS QTY RANK
RANK : Japan only
C131 Monolithic Ceramic Cap. SL 220P 50V J 01
C132 Monolithic Ceramic Cap. B 6800P 50V K 01
C133 Monolithic Ceramic Cap. SL 100P 50V J 01
C134 Monolithic Ceramic Cap. SL 100P 50V J 01
C135 Monolithic Ceramic Cap. B 2200P 50V K 01
C136 Monolithic Ceramic Cap. B 2200P 50V K 01
C137 Monolithic Ceramic Cap. F 0.1 25V Z 01
C138 Monolithic Ceramic Cap. SL 100P 50V J 01
C139 Monolithic Ceramic Cap. F 0.1 25V Z 01
C140 Electrolytic Cap. (chip) 22 16V 01
C140 Electrolytic Cap. (chip) 22UF 16V 01
C141 Monolithic Ceramic Cap. B 2200P 50V K 01
C142 Electrolytic Cap. (chip) 220 16V UUR1C2 01
C143 Monolithic Ceramic Cap. B 1000P 50V K 01
C144 Monolithic Ceramic Cap. F 0.01 50V Z 01
C145 Monolithic Ceramic Cap. B 2200P 50V K 01
C146 Electrolytic Cap. (chip) 4.7 50V 01
C146 Electrolytic Cap. (chip) 4.7UF 50V 01
C147 Monolithic Ceramic Cap. SL 100P 50V J 01
C148 Monolithic Ceramic Cap. SL 47P 50V J 01
C149 Monolithic Ceramic Cap. F 0.1 25V Z 01
C150 Electrolytic Cap. (chip) 10 16V 01
C150 Electrolytic Cap. (chip) 10UF 16V 01
C151 Electrolytic Cap. (chip) 4.7 50V 01
C151 Electrolytic Cap. (chip) 4.7UF 50V 01
C152 Monolithic Ceramic Cap. SL 100P 50V J 01
C153 Monolithic Ceramic Cap. SL 47P 50V J 01
C154 Electrolytic Cap. (chip) 100 16V 01
C154 Electrolytic Cap. (chip) 100UF 16V 01
C155 Electrolytic Cap. (chip) 10 16V 01
C155 Electrolytic Cap. (chip) 10UF 16V 01
C156 Monolithic Ceramic Cap. F 0.1 25V Z 01
CN1 Connector Base Post PH- 8P TE 01
CN2 Connector Base Post PH-13P TE 01
CN3 Connector Base Post PH-14P TE 01
CN4 Wire Trap 52147 6P TE 01
CN5 Connector Base Post PH-12P TE 01
CN6 Connector Base Post PH- 5P TE 01
CN7 Connector Base Post PH- 6P TE 01
CN8 Connector Assembly SAN-SAN3P 350L-S
D1 Diode RLS-73 TE-11 01
-11 Diode RLS-73 TE-11 01
D12 Zener Diode UDZ 3.6BTE-17 3.6V 01
D13 Diode RLS-73 TE-11 01
-21 Diode RLS-73 TE-11 01
D22 Diode D3FP3 03
D23 Diode D1F60 01
D24 Diode D3FP3 03
D25 Diode D1F60 01
D26 Diode D1F60 01
D27 Diode RLS-73 TE-11 01
D28 Diode RLS-73 TE-11 01
EM1 LC Filter (chip) NFM41P11C204 01
-5 LC Filter (chip) NFM41P11C204 01
EM6 LC Filter STF-104ZB-TBM 01
EM7 LC Filter STF-104ZB-TBM 01
EM8 LC Filter (chip) NFM41P11C204 01
EM9 LC Filter (chip) NFM41P11C204 01
IC1 IC MC34051MEL
LINE TRANCEIVER
05
IC1 IC M5M34051FP 05
IC2 IC SC7SU04FEL INVERTER 01
IC3 IC TC74HC14AF-TP1 INVERTER 02
IC4 IC TC74HC14AF-TP1 INVERTER 02
IC5 IC TC74HC4053AF MULTIPLEXER 03
IC6 IC TC74HC4053AF MULTIPLEXER 03
IC7 IC HD6432655A00F CPU 11
IC8 IC M27C160-100F1 EPROM 16M
IC9 IC M5M51008BFP-70LLT SRAM 11
IC10 IC M5M51008BFP-70LLT SRAM 11
IC11 IC TC7S66F ANALOG SW 01
UB052220
UB013680
UB052100
UB052100
UB013220
UB013220
UB245100
UB052100
UB245100
UF037220
UG037220
UB013220
UF138220
UB013100
UB044100
UB013220
UF066470
UG066470
UB052100
UB051470
UB245100
UF037100
UG037100
UF066470
UG066470
UB052100
UB051470
UF038100
UG038100
UF037100
UG037100
UB245100
VB390400
VF283100
VE352600
VF728300
VB390800
VB390100
VB390200
VU820200
VV925900
VV925900
VU171500
VV925900
VV925900
VZ016600
VS201100
VZ016600
VS201100
VS201100
VV925900
VV925900
VT332800
VT332800
VR193800
VR193800
VT332800
VT332800
XP881A00
XV103A00
XI348A00
XD657A00
XD657A00
XR150A00
XR150A00
XT443A00
XV407B00
XS681A00
XS681A00
XR682A00






















Yamaha CS2x Specifications

General

Polyphony	64 voices
Multitimbral Capacity	16 parts
LFO	2 LFOs per voice
Keyboard	61 keys
Velocity Sensitivity	Yes
Aftertouch	No
Control	Pitch bend, Modulation wheel
Weight	6.5 kg
Year Released	1998
Type	Synthesizer
Oscillators	AWM2
Filter	Resonant filter
Effects	Reverb, Chorus, Variation
Storage	Internal memory for patches
MIDI	In, Out, Thru
Outputs	Stereo output, Headphone output
Inputs	Sustain pedal, Foot controller
Memory	128 user voices
Connections	MIDI (In/Out/Thru), Foot Controller, Foot Switch
