Yamaha CS2x Service Manual

CS2X
7
: New Parts
REF NO. PART NO. DESCRIPTION REMARKS QTY RANK
RANK : Japan only
IC12 IC M62021FP RESET 04
IC13 IC SN74HC245NSR BUFFER 04
IC14 IC SI-8050S REGULATOR +5V 05
IC15 IC UPC2909T-E1 REGULATOR +9V 03
IC16 IC UPC2933T-E1 REGULATOR +3.3V 03
IC17 IC TC203C760HF-002 SWP30B 19
IC18 IC KM23C64000G-KF74B5 ROM
IC19 IC KM23C64000G-KF74B6 ROM
IC20 IC M5M44260CTP-7 16
IC20 IC MSM514260C-60TS-K
DRAM 4M
16
IC21 IC NJM78L05UA REGULATOR +5V 02
IC22 IC UPD63200GS-E1 DAC 07
IC23 IC UPC4570G2 OP AMP 03
-26 IC UPC4570G2 OP AMP 03
IC27 IC NJM4556AMT1 OP AMP 03
IS1 IC Socket DICF-42CS-E 03
JK1 Phone Jack YKB21-5010 PHONES 01
JK2 Phone Jack LGR4609-7000 OUTPUT L/MONO 01
JK3 Phone Jack LGR4609-7000 OUTPUT R 01
JK4 DC-IN Jack 16V DC 3A HEC2305 DC IN 01
JK5 Phone Jack LGR4609-7000 FOOT (VOLUME,CONTROL) 01
-7 Phone Jack LGR4609-7000 FOOT SWITCH 01
JK8 Phone Jack ST HSJ0912 INPUT 02
JK9 DIN Connector DIN 8P MD-S810 TO HOST 03
JK10 DIN Connector 3P YKF51-5067 MIDI IN 03
JK11 DIN Connector 3P YKF51-5054 MIDI (THRU,OUT) 04
L1 Chip Solid Inductance BLM31A700SPT 70 01
-3 Chip Solid Inductance BLM31A700SPT 70 01
L4 Chip Inductance 56U LEM2520 T 560J 01
-9 Chip Inductance 56U LEM2520 T 560J 01
L10 Chip Inductance BK2125HS601-T 01
-15 Chip Inductance BK2125HS601-T 01
L16 Chip Solid Inductance BLM31A700SPT 70 01
L17 Chip Inductance 56U LEM2520 T 560J 01
L18 Chip Inductance 56U LEM2520 T 560J 01
L19 Chip Solid Inductance BLM31A700SPT 70 01
L20 Chip Solid Inductance BLM31A700SPT 70 01
L21 Chip Inductance 56U LEM2520 T 560J 01
-24 Chip Inductance 56U LEM2520 T 560J 01
L25 Chip Inductance BK2125HS601-T 01
-32 Chip Inductance BK2125HS601-T 01
L33 Chip Inductance BK2125HS601-T 01
-58 Chip Inductance BK2125HS601-T 01
L59 LC Filter PLT2003C 04
L60 Coil HP-022J 180U 05
L61 Chip Solid Inductance BLM31A700SPT 70 01
L62 Chip Inductance 56U LEM2520 T 560J 01
L63 Chip Inductance 56U LEM2520 T 560J 01
L64 Chip Solid Inductance BLM31A700SPT 70 01
L65 Chip Inductance 56U LEM2520 T 560J 01
L66 Chip Solid Inductance BLM31A700SPT 70 01
L67 Chip Inductance 56U LEM2520 T 560J 01
L68 Chip Solid Inductance BLM31A700SPT 70 01
L69 Chip Inductance 56U LEM2520 T 560J 01
L70 Chip Inductance 56U LEM2520 T 560J 01
L71 Chip Inductance BK2125HS601-T 01
L72 Chip Solid Inductance BLM21P300SPT 01
PC1 Photo Coupler HCPL-M600 04
R1 Carbon Resistor (chip) 220.0 0.1 J 01
R2 Carbon Resistor (chip) 2.7K 0.1 J 01
R3 Carbon Resistor (chip) 1.0K 0.1 J 01
R4 Carbon Resistor (chip) 220.0 0.1 J 01
R5 Carbon Resistor (chip) 2.7K 0.1 J 01
R6 Carbon Resistor (chip) 1.0K 0.1 J 01
R7 Carbon Resistor (chip) 4.7K 0.1 J 01
R8 Carbon Resistor (chip) 100.0K 0.1 J 01
R9 Carbon Resistor (chip) 22.0K 0.1 J 01
R10 Carbon Resistor (chip) 56.0 0.1 J 01
R11 Carbon Resistor (chip) 56.0 0.1 J 01
R12 Carbon Resistor (chip) 4.7K 0.1 J 01
XI686A00
XD838A00
XT442A00
XT441A00
XS516A00
XS725A00
XV537A00
XV538A00
XS438A00
XU462A00
XJ598A00
XP867A00
XF291A00
XF291A00
XQ138A00
VK863100
VE382300
VS115400
VS115400
VJ207400
VS115400
VS115400
LB302010
VM761000
VT033600
VJ885500
VL139800
VL139800
VR243700
VR243700
VR579900
VR579900
VL139800
VR243700
VR243700
VL139800
VL139800
VR243700
VR243700
VR579900
VR579900
VR579900
VR579900
VG238200
VZ017900
VL139800
VR243700
VR243700
VL139800
VR243700
VL139800
VR243700
VL139800
VR243700
VR243700
VR579900
VU954000
VR903700
RD255220
RD256270
RD256100
RD255220
RD256270
RD256100
RD256470
RD258100
RD257220
RD254560
RD254560
RD256470
*
*




Yamaha CS2x Specifications

General

Polyphony	64 voices
Multitimbral Capacity	16 parts
LFO	2 LFOs per voice
Keyboard	61 keys
Velocity Sensitivity	Yes
Aftertouch	No
Control	Pitch bend, Modulation wheel
Weight	6.5 kg
Year Released	1998
Type	Synthesizer
Oscillators	AWM2
Filter	Resonant filter
Effects	Reverb, Chorus, Variation
Storage	Internal memory for patches
MIDI	In, Out, Thru
Outputs	Stereo output, Headphone output
Inputs	Sustain pedal, Foot controller
Memory	128 user voices
Connections	MIDI (In/Out/Thru), Foot Controller, Foot Switch
