Yamaha CS2x Service Manual

CS2X
8
: New Parts
REF NO. PART NO. DESCRIPTION REMARKS QTY RANK
RANK : Japan only
R13 Carbon Resistor (chip) 1.0K 0.1 J 01
R14 Carbon Resistor (chip) 10.0K 0.1 J 01
R15 Carbon Resistor (chip) 1.0K 0.1 J 01
R16 Carbon Resistor (chip) 22.0K 0.1 J 01
R17 Carbon Resistor (chip) 22.0K 0.1 J 01
R18 Carbon Resistor (chip) 220.0 0.1 J 01
R19 Carbon Resistor (chip) 1.0K 0.1 J 01
R20 Carbon Resistor (chip) 220.0 0.1 J 01
-23 Carbon Resistor (chip) 220.0 0.1 J 01
R24 Carbon Resistor (chip) 680.0 0.1 J 01
R25 Carbon Resistor (chip) 680.0K 0.1 J 01
R26 Carbon Resistor (chip) 1.0K 0.1 J 01
R32 Carbon Resistor (chip) 1.0K 0.1 J 01
R33 Carbon Resistor (chip) 68.0 0.1 J 01
R34 Carbon Resistor (chip) 10.0K 0.1 J 01
R37 Carbon Resistor (chip) 1.5K 0.1 J 01
R38 Carbon Resistor (chip) 10.0K 0.1 J 01
-41 Carbon Resistor (chip) 10.0K 0.1 J 01
R42 Carbon Resistor (chip) 1.0K 0.1 J 01
-49 Carbon Resistor (chip) 1.0K 0.1 J 01
R50 Carbon Resistor (chip) 10.0 0.1 J 01
R51 Metal Film Resistor (chip) 10.0K 1/10 D 01
R52 Metal Film Resistor (chip) 10.0K 1/10 D 01
R53 Carbon Resistor (chip) 47.0K 0.1 J 01
R54 Carbon Resistor (chip) 47.0K 0.1 J 01
R55 Carbon Resistor (chip) 10.0 0.1 J 01
R56 Carbon Resistor (chip) 47.0K 0.1 J 01
R57 Carbon Resistor (chip) 470.0 0.1 J 01
R58 Carbon Resistor (chip) 470.0 0.1 J 01
R59 Carbon Resistor (chip) 56.0 1/4 J 01
R60 Carbon Resistor (chip) 56.0 1/4 J 01
R61 Carbon Resistor (chip) 10.0K 0.1 J 01
R62 Carbon Resistor (chip) 10.0K 0.1 J 01
R64 Carbon Resistor (chip) 10.0K 0.1 J 01
R65 Carbon Resistor (chip) 1.5K 0.1 J 01
R66 Carbon Resistor (chip) 10.0K 0.1 J 01
R67 Carbon Resistor (chip) 6.8K 0.1 J 01
R68 Carbon Resistor (chip) 15.0K 0.1 J 01
R69 Carbon Resistor (chip) 6.8K 0.1 J 01
R70 Carbon Resistor (chip) 1.0K 0.1 J 01
R72 Carbon Resistor (chip) 10.0K 0.1 J 01
-74 Carbon Resistor (chip) 10.0K 0.1 J 01
R75 Carbon Resistor (chip) 100.0K 0.1 J 01
R76 Carbon Resistor (chip) 27.0K 0.1 J 01
R77 Carbon Resistor (chip) 12.0K 0.1 J 01
R78 Carbon Resistor (chip) 10.0K 0.1 J 01
R79 Carbon Resistor (chip) 18.0K 0.1 J 01
R80 Carbon Resistor (chip) 470.0 1/4 J
R81 Carbon Resistor (chip) 10.0K 0.1 J 01
R82 Carbon Resistor (chip) 1.0K 0.1 J 01
R83 Carbon Resistor (chip) 1.0K 0.1 J 01
R84 Carbon Resistor (chip) 10.0K 0.1 J 01
R85 Carbon Resistor (chip) 47.0 1/4 J 01
R86 Carbon Resistor (chip) 6.8K 0.1 J 01
R87 Carbon Resistor (chip) 15.0K 0.1 J 01
R88 Carbon Resistor (chip) 6.8K 0.1 J 01
R89 Carbon Resistor (chip) 1.0K 0.1 J 01
R91 Carbon Resistor (chip) 10.0K 0.1 J 01
-93 Carbon Resistor (chip) 10.0K 0.1 J 01
R94 Carbon Resistor (chip) 100.0K 0.1 J 01
R95 Carbon Resistor (chip) 27.0K 0.1 J 01
R96 Carbon Resistor (chip) 12.0K 0.1 J 01
R97 Carbon Resistor (chip) 10.0K 0.1 J 01
R98 Carbon Resistor (chip) 18.0K 0.1 J 01
R99 Carbon Resistor (chip) 10.0K 0.1 J 01
R100 Carbon Resistor (chip) 1.0K 0.1 J 01
R101 Carbon Resistor (chip) 1.0K 0.1 J 01
R102 Carbon Resistor (chip) 10.0K 0.1 J 01
R103 Carbon Resistor (chip) 47.0 1/4 J 01
R105 Carbon Resistor (chip) 22.0K 0.1 J 01
RD256100
RD257100
RD256100
RD257220
RD257220
RD255220
RD256100
RD255220
RD255220
RD255680
RD258680
RD256100
RD256100
RD254680
RD257100
RD256150
RD257100
RD257100
RD256100
RD256100
RD254100
VI197400
VI197400
RD257470
RD257470
RD254100
RD257470
RD255470
RD255470
RD154560
RD154560
RD257100
RD257100
RD257100
RD256150
RD257100
RD256680
RD257150
RD256680
RD256100
RD257100
RD257100
RD258100
RD257270
RD257120
RD257100
RD257180
RD155470
RD257100
RD256100
RD256100
RD257100
RD154470
RD256680
RD257150
RD256680
RD256100
RD257100
RD257100
RD258100
RD257270
RD257120
RD257100
RD257180
RD257100
RD256100
RD256100
RD257100
RD154470
RD257220

Yamaha CS2x Specifications

General

Polyphony	64 voices
Multitimbral Capacity	16 parts
LFO	2 LFOs per voice
Keyboard	61 keys
Velocity Sensitivity	Yes
Aftertouch	No
Control	Pitch bend, Modulation wheel
Weight	6.5 kg
Year Released	1998
Type	Synthesizer
Oscillators	AWM2
Filter	Resonant filter
Effects	Reverb, Chorus, Variation
Storage	Internal memory for patches
MIDI	In, Out, Thru
Outputs	Stereo output, Headphone output
Inputs	Sustain pedal, Foot controller
Memory	128 user voices
Connections	MIDI (In/Out/Thru), Foot Controller, Foot Switch
