Yamaha CS2x - Page 51

CS2X
9
: New Parts
REF NO. PART NO. DESCRIPTION REMARKS QTY RANK
RANK : Japan only
R106 Carbon Resistor (chip) 18.0K 0.1 J 01
R107 Carbon Resistor (chip) 20.0K 0.1 J 01
R109 Carbon Resistor (chip) 22.0K 0.1 J 01
R110 Carbon Resistor (chip) 18.0K 0.1 J 01
R111 Carbon Resistor (chip) 20.0K 0.1 J 01
R112 Carbon Resistor (chip) 10.0 0.1 J 01
R113 Carbon Resistor (chip) 150.0 0.1 J 01
R114 Carbon Resistor (chip) 68.0 0.1 J 01
R115 Carbon Resistor (chip) 47.0K 0.1 J 01
R116 Carbon Resistor (chip) 100.0K 0.1 J 01
RA1 Resistor Array 22KX4 01
RA2 Resistor Array 68X4 01
-6 Resistor Array 68X4 01
RA7 Resistor Array 10KX4 01
RA8 Resistor Array 22KX4 01
-11 Resistor Array 22KX4 01
RA12 Resistor Array 68X4 01
-15 Resistor Array 68X4 01
RA16 Resistor Array 10KX4 01
-18 Resistor Array 10KX4 01
RA19 Resistor Array 68X4 01
RA20 Resistor Array 22KX4 01
RA21 Resistor Array 10KX4 01
-24 Resistor Array 10KX4 01
RA25 Resistor Array 68X4 01
RA26 Resistor Array 47KX4 01
-29 Resistor Array 47KX4 01
RA30 Resistor Array 68X4 01
-57 Resistor Array 68X4 01
SP1 Style Pin IMSA-6024 01
SW1 Push Switch SDDLB1 POWER 03
SW2 Slide Switch SSSF12539A HOST SELECT 03
TR1 Transistor 2SC3326 A,B TE85R 01
TR2 Transistor 2SC3326 A,B TE85R 01
TR3 Transistor 2SA1162 O,Y 01
TR4 Transistor 2SC3326 A,B TE85R 01
X1 Quartz Crystal Unit 16M SMD-49 04
X2 Quartz Crystal Unit DOC-49S5 05
Circuit Board LC (XR661B0) 11
Circuit Board LE (XR661B0) 09
Pin Header A4B-5PA-2DS 01
C1 Semiconductive Cera. Cap. 0.1 25V M 01
CN1 Connector Assembly 14P-450 06
R1 Carbon Resistor 330.0 1/4 J 01
R2 Carbon Resistor 10.0K 1/4 J 01
R3 Carbon Resistor 91.0K 1/4 J 01
RA1 Resistor Array EXBF6N102J 01
IC1 IC LC7985ND LCD CONTROLLER 06
D3 LED GL1EG211 GR LCD back-lit 01
-8 LED GL1EG211 GR 01
Circuit Board MK-L (XR564B0) 09
Diode 1SS133,1SS176 01
Wire Trap 52147 12P TE 01
Wire Trap 52147 7P TE 01
Circuit Board MK-H (XR565B0) 09
Diode 1SS133,1SS176 01
Wire Trap 52147 12P TE 01
Wire Trap 52147 5P TE 01
Circuit Board 16M MKS2 (XS829A0)(XR736C0) 10
Vibration-proof Tape 10X64X0.5 (VK34680) 10
Jumper Wire 0.55 (VA07890) 40
C1 Ceramic Capacitor-SL 22P 50V J 01
C1 Ceramic Capacitor 22P 63V J 01
C2 Ceramic Capacitor-SL 22P 50V J 01
C2 Ceramic Capacitor 22P 63V J 01
C3 Electrolytic Cap. 100.00 10.0V 01
RD257180
RD257200
RD257220
RD257180
RD257200
RD254100
RD255150
RD254680
RD257470
RD258100
RE047220
RE044680
RE044680
RE047100
RE047220
RE047220
RE044680
RE044680
RE047100
RE047100
RE044680
RE047220
RE047100
RE047100
RE044680
RE047470
RE047470
RE044680
RE044680
VB966900
VP691000
VT761300
VD303700
VD303700
VJ927200
VD303700
VP864900
VV345500
VU407800
VU617900
VU619100
VD930900
VU554300
HF455330
HF457100
HF457910
VR538200
XN859A00
VU767400
VU767400
VU648100
VB941200
VK025600
VK025100
VU648200
VB941200
VK025600
VK024900
VU494600
--
--
FG651220
VR027400
FG651220
VR027400
UJ828100






