Yamaha CS2x Service Manual

CS2X
10
*
*
: New Parts
REF NO. PART NO. DESCRIPTION REMARKS QTY RANK
RANK : Japan only
C4 Semiconductive Cera. Cap. 0.1 25V M 01
C4 Carbon Resistor 0.1 25V Z 01
CL1 Ceramic Resonator CST8.00MTW140 02
CL1 Ceramic Resonator 8.00M EFOEC8004T3 02
CN1 Wire Trap 52147 6P TE 01
CN2 Wire Trap 52147 12P TE 01
CN3 Wire Trap 52147 7P TE 01
CN4 Wire Trap 52147 5P TE 01
IC1 IC HD63B05V0F07P CPU 06
R1 Carbon Resistor 4.7K 1/4 J 01
R1 Carbon Resistor 4.7K 1/6 J 01
R2 Carbon Resistor 4.7K 1/4 J 01
R2 Carbon Resistor 4.7K 1/6 J 01
R3 Carbon Resistor 47.0K 1/4 J 01
R3 Carbon Resistor 47.0K 1/6 J 01
RA1 Resistor Array RGLE12X473J 01
Circuit Board PN 1/2 (XR660B0)
Circuit Board PN 2/2 (XR660B0)
Jumper Wire 0.55 (VA07890)
CN1 Connector Assembly 6P-250 (VU40630)
CN2 Connector Assembly 12P-300 (VU40660)
CN3 Connector Assembly 13P-160 (VU40610)
CN5 Connector Assembly 13P-300 (VU47340)
CN6 Connector Assembly 8P-250 (VU40650)
D1 Diode 1SS133,176,HSS104 01
-8 Diode 1SS133,176,HSS104 01
LE1 Circuit Board LE 09
LE2 Circuit Board LE 09
LED1 LED SEL2210W TP8 RE SCENE 1 01
LED2 LED SEL2210W TP8 RE SCENE 2 01
RTSW1 Rotary Switch SRBV16036A Dial 04
SW1 Tact Switch SKQNAE025A SCENE(1,2),ARPEGGIO,SHIFT 01
-46 Tact Switch SKQNAE025A PART/LAYER(+,-),PRESET, 01
USER,PROGURAM(+,-),0to9,
-,ENTER,PERFORMANCE,
MULTI,STORE,UTILITY,
(all up,down switch)
VR1 Rotary Variable Resistor A 30.0K RK14K12C VOLUME 03
VR2 Rotary Variable Resistor B 10.0K RK11K113 ATTACK,DECAY,RELEASE, 02
-9 Rotary Variable Resistor B 10.0K RK11K113 HPF CUTOFF,LPF CUTOFF, 02
RESONANSE,ASSIGN 1/DATA,
ASSIGN 2
AC Adapter PA-3B JP J 09
AC Adapter PA-3B UC U
AC Adapter PA-3B CEE E 08
Lithium Battery CR2032 03
LCD LCD5853H 06
Rotary Variable Resistor RK1631110T54Aĸ10K PITCH 03
Rotary Variable Resistor 10.0K K161100S MODULATION
VD930900
VM902400
VN002100
VQ305500
VF728300
VK025600
VK025100
VK024900
XR951A00
HF456470
VL631400
HF456470
VL631400
HF457470
VL632600
VH373200
NX820420
NX820430
--
--
--
--
--
--
VD631600
VD631600
VU617900
VU617900
VS704700
VS704700
VU411100
VV056000
VV056000
VT683300
VQ032500
VQ032500
VT368600
VT368700
VT368800
VN103500
VU421400
VQ764300
VN245400
















Yamaha CS2x Specifications

General

Polyphony	64 voices
Multitimbral Capacity	16 parts
LFO	2 LFOs per voice
Keyboard	61 keys
Velocity Sensitivity	Yes
Aftertouch	No
Control	Pitch bend, Modulation wheel
Weight	6.5 kg
Year Released	1998
Type	Synthesizer
Oscillators	AWM2
Filter	Resonant filter
Effects	Reverb, Chorus, Variation
Storage	Internal memory for patches
MIDI	In, Out, Thru
Outputs	Stereo output, Headphone output
Inputs	Sustain pedal, Foot controller
Memory	128 user voices
Connections	MIDI (In/Out/Thru), Foot Controller, Foot Switch
