DSP-A5
■ TO SERVICE PERSONNEL
1. Critical Components information
Components having special characteristics are marked
!
and must be
replaced with parts having specifications equal to those originally
installed.
2. Leakage Current Measurement (For 120V Model only)
When service has been completed, it is imperative that you verify that
all exposed conductive surfaces are properly insulated from supply
circuits.
•
Meter impedance should be equivalent to 1500 ohm shunted by 0.15µF.
•
Leakage current must not exceed 0.5mA.
•
Be sure to test for leakage with the AC plug in both polarities.
WARNING: CHEMICAL CONTENT NOTICE!
The solder used in the production of this product contains LEAD. In addition, other electrical/electronic and/or plastic (where
applicable) components may also contain traces of chemicals found by the California Health and Welfare Agency (and possibly
other entities) to cause cancer and/or birth defects or other reproductive harm.
DO NOT PLACE SOLDER, ELECTRICAL/ELECTRONIC OR PLASTIC COMPONENTS IN YOUR MOUTH FOR ANY REASON
WHATSOEVER!
Avoid prolonged, unprotected contact between solder and your skin! When soldering, do not inhale solder fumes or expose eyes
to solder/flux vapor!
If you come in contact with solder or components located inside the enclosure of this product, wash your hands before handling
food.
■ REMOTE CONTROL PANELS
▼ R and T models ▼ B and G models
WALL
OUTLET
EQUIPMENT
UNDER TEST
AC LEAKAGE
TESTER OR
EQUIVALENT
INSULATING
TABLE
D
V
D
/
L
D
DSP INPUT
MOVIE
THTR 1
MONO MOVIE
TV SPORTS
DISCO
ROCK HALL
EXT.DEC. INDEX
EFFECT
/DTS
SUR.
MOVIE
THTR 2
2
TUNER
3
TAPE/MD
1
CD
5
D-TV
6
VCR
4
DVD/LD
8
CBL/SAT
9
V-AUX
7
PHONO
ENTER >10
+
+
--
+
--
0
A/B/C/D/E
POWER
SELECT
AV
DIR A DIR B
DISC SKIP
PRESET
CHCH
A/B
DISPLAYVCR REC
TEST
MENUTITLE
TV
POWER
TV
SLEEP
VOLUMETV VOL
MUTE
INPUT
STANDBY
POWER
I
SET MENUTIME/LEVEL
RAV210
V429760 US
--
