56
DSP-A5
Schm
Ref
PART NO. Description
✻ New Parts
✻ New Parts
Schm
Ref
PART NO. Description
P. C. B. DSP & P. C. B. OPERATION
C138 UB245100 C.CE.M.CHP 0.1uF 25V
C139 UB052100 C.CE.M.CHP 100pF 50V
C140 UB052100 C.CE.M.CHP 100pF 50V
C141 UB052100 C.CE.M.CHP 100pF 50V
C150 UB052100 C.CE.M.CHP 100pF 50V
C151 UB012330 C.CE.M.CHP 330pF 50V
C152 UB052100 C.CE.M.CHP 100pF 50V
C153 UB012330 C.CE.M.CHP 330pF 50V
C154 UB052100 C.CE.M.CHP 100pF 50V
C155 UB012330 C.CE.M.CHP 330pF 50V
C156 UB052100 C.CE.M.CHP 100pF 50V
C157 UB052100 C.CE.M.CHP 100pF 50V
C158 UB052100 C.CE.M.CHP 100pF 50V
C159 UB012560 C.CE.M.CHP 560pF 50V
C160 UB052100 C.CE.M.CHP 100pF 50V
C161 UB052100 C.CE.M.CHP 100pF 50V
C162 UB052100 C.CE.M.CHP 100pF 50V
C163 UB052100 C.CE.M.CHP 100pF 50V
C164 UB012330 C.CE.M.CHP 330pF 50V
C165 UB052100 C.CE.M.CHP 100pF 50V
C166 UA952680 C.MYLAR 680pF 50V
C167 UA952680 C.MYLAR 680pF 50V
C168 UA952150 C.MYLAR 150pF 50V
C169 UA952150 C.MYLAR 150pF 50V
C170 UB245100 C.CE.M.CHP 0.1uF 25V
C175 UB245100 C.CE.M.CHP 0.1uF 25V
D1 VT332900 DIODE 1SS355
D2 VT332900 DIODE 1SS355
D4 VT332900 DIODE 1SS355
D5 VT332900 DIODE 1SS355
D6 VT332900 DIODE 1SS355
D7 VT332900 DIODE 1SS355
D8 VT332900 DIODE 1SS355
D9 VT332900 DIODE 1SS355
D10 VT332900 DIODE 1SS355
D11 VT332900 DIODE 1SS355
D12 VT332900 DIODE 1SS355
D14 VT332900 DIODE 1SS355
D15 VT332900 DIODE 1SS355
D16 VT332900 DIODE 1SS355
D17 VT332900 DIODE 1SS355
D150 VT332900 DIODE 1SS355
D151 VT332900 DIODE 1SS355
D152 VT332900 DIODE 1SS355
G1 VR463400 TERM.GND D3.5 TP00385
G2 VR463400 TERM.GND D3.5 TP00385
G3 VR463400 TERM.GND D3.5 TP00385
G4 VR463400 TERM.GND D3.5 TP00385
IC1 XR038A00 IC NJM2904M OP AMP
IC2 XL091A00 IC HD74HC02FPEL NOR
IC3 XW526A00 IC YSD917
IC4 XV304B00 IC YSS918D-F
IC5 XV305A00 IC IS61C1024-20J SRAM
IC6 XV951A00 IC AK4526A-VQ
IC7 XT955A00 IC AK4324-VF-E2
IC8 XF291A00 IC uPC4570G2
IC9 XF291A00 IC uPC4570G2
IC10 XF291A00 IC uPC4570G2
IC11 XF291A00 IC uPC4570G2
IC13 XF291A00 IC uPC4570G2
IC15 XU965A00 IC uPC29M33T-E1 3.3V
Q1 VV655300 TR.DGT DTA144EKA
Q2 VV655300 TR.DGT DTA144EKA
Q3 VV655300 TR.DGT DTA144EKA
Q4 VD303700 TR 2SC3326 A,B
Q5 VD303700 TR 2SC3326 A,B
Q6 VD303700 TR 2SC3326 A,B
Q7 VD303700 TR 2SC3326 A,B
Q8 VD303700 TR 2SC3326 A,B
Q9 VD303700 TR 2SC3326 A,B
Q10 VD303700 TR 2SC3326 A,B
Q11 VD303700 TR 2SC3326 A,B
Q12 VD303700 TR 2SC3326 A,B
Q13 VD303700 TR 2SC3326 A,B
Q14 VV655700 TR.DGT DTC144EKA
R30 HV753220 R.CAR.FP 2.2Ω 1/4W
R36 HV753220 R.CAR.FP 2.2Ω 1/4W
R37 HV753220 R.CAR.FP 2.2Ω 1/4W
R43 HV754100 R.CAR.FP 10Ω 1/4W
R44 HV754100 R.CAR.FP 10Ω 1/4W
R45 HV753100 R.CAR.FP 1Ω 1/4W
R47 HV753100 R.CAR.FP 1Ω 1/4W
R114 HV753220 R.CAR.FP 2.2Ω 1/4W
R115 HV753220 R.CAR.FP 2.2Ω 1/4W
R170 HV753220 R.CAR.FP 2.2Ω 1/4W
XL1 V3625700 RSNR.CRYS 24.576MHz
V4801400 P.C.B. OPERATION(RT)
V4801500 P.C.B. OPERATION(BG)
CB501 VU273500 CN 35P
CB502 VU270800 CN 8P
CB503 Vi878800 CN.BS.PIN 10P
CB581 Vi878700 CN.BS.PIN 9P
CB621 VQ047100 CN.BS.PIN 7P
C501 UR866220 C.EL 2.2uF 50V
C502 VG278900 C.CE.TUBLR 680pF 50V
C503 VG278900 C.CE.TUBLR 680pF 50V
C504 UR866100 C.EL 1uF 50V
C505 VJ599100 C.CE.TUBLR 0.1uF 50V
C506 UR819100 C.EL 1000uF 6.3V
C507 UR819100 C.EL 1000uF 6.3V
C508 VS672200 C.EL 4700uF 5.5V
C509 VJ599100 C.CE.TUBLR 0.1uF 50V
C510 UR847100 C.EL 10uF 25V
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
