57
DSP-A5
P. C. B. OPERATION & P. C. B. INPUT
Schm
Ref
PART NO. Description
✻ New Parts
✻ New Parts
Schm
Ref
PART NO. Description
C511 VJ599100 C.CE.TUBLR 0.1uF 50V
C512 UR847470 C.EL 47uF 25V
C513 VJ599100 C.CE.TUBLR 0.1uF 50V
C514 VJ599100 C.CE.TUBLR 0.1uF 50V
C515 VJ599100 C.CE.TUBLR 0.1uF 50V
C516 VJ599100 C.CE.TUBLR 0.1uF 50V
C581 VG291300 C.EL 100uF 50V
C582 VG291300 C.EL 100uF 50V
C583 VG290500 C.EL 1uF 50V
C584 V5690300 C.PP 47pF 100V
C585 VG290600 C.EL 2.2uF 50V
C586 V5690300 C.PP 47pF 100V
C587 VG290600 C.EL 2.2uF 50V
C588 VG290500 C.EL 1uF 50V
C589 UU137470 C.EL 47uF 16V
C590 UA655120 C.MYLAR 0.12uF 50V
C591 UA954330 C.MYLAR 0.033uF 50V
C592 UA954330 C.MYLAR 0.033uF 50V
C593 UA655120 C.MYLAR 0.12uF 50V
C594 UU137470 C.EL 47uF 16V
C595 UU137100 C.EL 10uF 16V
C596 VQ645600 C.MYLAR 100pF 50V
C597 VQ645600 C.MYLAR 100pF 50V
C598 UU137100 C.EL 10uF 16V
C599 UU137100 C.EL 10uF 16V
C600 UU137100 C.EL 10uF 16V
C621 VJ599100 C.CE.TUBLR 0.1uF 50V
C622 VJ599100 C.CE.TUBLR 0.1uF 50V
C623 VF466800 C.CE.TUBLR 100pF 50V
C624 VF466800 C.CE.TUBLR 100pF 50V
D501 VD631600 DIODE 1SS133,176,HSS104
D502 VD631600 DIODE 1SS133,176,HSS104
D503 VD631600 DIODE 1SS133,176,HSS104
D504 VD631600 DIODE 1SS133,176,HSS104
D505 VM974100 DIODE.ZENR HZS5B2TD 5.0V
D506 VM974100 DIODE.ZENR HZS5B2TD 5.0V
D507 VD631600 DIODE 1SS133,176,HSS104
D508 VM974700 DIODE.ZENR HZS7B2TD 7.0V
D509 VD631600 DIODE 1SS133,176,HSS104
D510 VD631600 DIODE 1SS133,176,HSS104
D511 VM974400 DIODE.ZENR HZS6B2TD 6.0V(RT)
D511 VM974600 DIODE.ZENR HZS7A2TD 7.0V(BG)
D512 VD631600 DIODE 1SS133,176,HSS104
IC501 XW826A00 IC.CPU M30217MA-A203FP
IC502 XJ757A00 IC NJM78L05A-T3
IC581 XA987A00 IC NJM2068D-D
IC582 XA987A00 IC NJM2068D-D
JK621 V2589500 CN 1P
PJ621 VR406000 JACK.PIN 3P
PN501 V3750200 PIN L=70
Q501 iA093320 TR 2SA933S Q,R
Q502 iA093320 TR 2SA933S Q,R
Q503 VG722000 TR.DGT DTC144ES
Q504 iA093320 TR 2SA933S Q,R
Q505 VR948600 TR 2SC4038 Q,R,S
Q506 VR948600 TR 2SC4038 Q,R,S
R581 VP940200 R.MTL.OXD 47Ω 1W
R582 VP940200 R.MTL.OXD 47Ω 1W
ST601 BB071360 SCR.TERM 8.3x13
SW501 V4586200 SW.RT.ENC REB161PVB20F
SW502 VG392900 SW.TACT SKHVAA
SW503 VG392900 SW.TACT SKHVAA
SW504 VG392900 SW.TACT SKHVAA
SW505 VG392900 SW.TACT SKHVAA
SW506 VG392900 SW.TACT SKHVAA
SW507 VG392900 SW.TACT SKHVAA
SW508 VG392900 SW.TACT SKHVAA
SW509 VG392900 SW.TACT SKHVAA
SW510 VG392900 SW.TACT SKHVAA
U501 V3872300 L.DTCT PIC-28143TH5
V501 V4193300 FL.DSPLY 16-BT-71GK
VR581 VP741800 VR B20KΩ
VR582 VP741900 VR G25KΩ
VR583 VP742000 VR MN100KΩ
XL501 V4610100 RSNR.CE 10MHz
VS588900 SHEET
V4186900 SPACER FL-WIDE 10/32
V4800600 P.C.B. INPUT(RT)
V4800700 P.C.B. INPUT(BG)
CB102 VM923600 CN.BS.PIN 13P
CB103 Vi878900 CN.BS.PIN 11P
CB104 VQ048400 CN 35P
CB105 VM689000 CN.BS.PIN 23P
CB106 VQ047400 CN.BS.PIN 19P
CB108 VK025300 CN.BS.PIN 9P
CB110 VQ047500 CN.BS.PIN 20P
CB112 Vi878900 CN.BS.PIN 11P
CB301 Vi878800 CN.BS.PIN 10P
CB302 VK027000 CN.BS.PIN 11P
CB303 VQ047100 CN.BS.PIN 7P
CB331 Vi878900 CN.BS.PIN 11P
CB351 Vi878800 CN.BS.PIN 10P
CB371 V5478200 CN.PHOT.SN 1P GP1FA551RZ
CB372 V5478200 CN.PHOT.SN 1P GP1FA551RZ
CB373 V5478200 CN.PHOT.SN 1P GP1FA551RZ
CB374 VQ044300 CN.BS.PIN 7P
C102 UA952100 C.MYLAR 100pF 50V(BG)
C103 UA952220 C.MYLAR 220pF 50V
C104 UA952100 C.MYLAR 100pF 50V
C105 UA952220 C.MYLAR 220pF 50V
C107 VF467300 C.CE.TUBLR 0.01uF 16V
C108 VK533900 C.PP 100pF 200V
C109 VK533900 C.PP 100pF 200V
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
✻
