4
DSP-A5
● DIMENSIONS
Units: mm (inch)
21.5
(7/8")
435(17-1/8")
349.5(13-3/4")
390.5(15-3/8")
130(5-3/32")
151(5-15/16")
19.5
(13/16")
21
(27/32")
WARNING
Do not change the IMPEDANCE SELECTOR switch
setting while the power to this unit is on, otherwise
this unit may be damaged.
IMPEDANCE SELECTOR
Manufactured under license from Dolby Laboratories.
"DOLBY", "AC-3", "PRO LOGIC", and the double-D
symbol are trademarks of Dolby Laboratories.
Confidential unpublished works.
©1992-1997 Dolby Laboratories. All rights reserved.
Manufactured under license from Digital Theater
Systems, Inc. US Pat. No. 5,451,942 and other world-
wide patents issued and pending. "DTS", "DTS
Digital Surround", are trademarks of Digital Theater
Systems, Inc. Copyright 1996 Digital Theater
Systems, inc. All rights reserved.
