58
DSP-A595
P. C. B. INPUT & P. C. B. MAIN
Schm
Ref
PART NO. Description
✻ New Parts✻ New Parts
Schm
Ref
PART NO. Description
PJ101 VQ260900 JACK.PIN 4P
PJ102 VV306900 JACK.PIN 4P
PJ103 VV306900 JACK.PIN 4P
PJ104 VU857800 JACK.PIN 6P
PJ105 VK437600 JACK.PIN 1P
PJ301 VV325000 JACK.PIN 2P
PJ302 VV852500 JACK.PIN 3P
PJ351 V2874800 JACK.PIN 6P
PJ352 VY667700 JACK.PIN 1P
Q101 iC287820 TR 2SC2878 A,B
Q301 iA1015I0 TR 2SA1015 Y
Q302 iC1815I0 TR 2SC1815 Y
Q303 iA1015I0 TR 2SA1015 Y
Q304 iC1815I0 TR 2SC1815 Y
Q305 iC1815I0 TR 2SC1815 Y
Q306 iC1815I0 TR 2SC1815 Y
Q307 iC174020 TR 2SC1740S R,S
R141 HV755100 R.CAR.FP 100Ω 1/4W
R154 HV755100 R.CAR.FP 100Ω 1/4W
R155 HV753220 R.CAR.FP 2.2Ω 1/4W
R156 HV753220 R.CAR.FP 2.2Ω 1/4W
R214 HV753220 R.CAR.FP 2.2Ω 1/4W
R215 HV753220 R.CAR.FP 2.2Ω 1/4W
R216 HV753220 R.CAR.FP 2.2Ω 1/4W
R217 HV753220 R.CAR.FP 2.2Ω 1/4W
R231 HV753220 R.CAR.FP 2.2Ω 1/4W
R232 HV753220 R.CAR.FP 2.2Ω 1/4W
R334 HV753220 R.CAR.FP 2.2Ω 1/4W
R373 HV753220 R.CAR.FP 2.2Ω 1/4W
R411 HV754100 R.CAR.FP 10Ω 1/4W
R412 HV754100 R.CAR.FP 10Ω 1/4W
R435 HV754100 R.CAR.FP 10Ω 1/4W
VR401 VV613500 VR A100KΩ
V3003700 P.C.B. MAIN(RT)
V3003800 P.C.B. MAIN(BG)
CB501 Vi878800 CN.BS.PIN 10P
CB502 VQ961600 CN 13P
CB503 VQ963400 CN.BS.PIN 13P
CB504 VQ585000 CN.BS.PIN 8P
CB505 VK025300 CN.BS.PIN 9P
CB506 VK024800 CN.BS.PIN 4P
CB507 VK024700 CN.BS.PIN 3P
CB701 VQ585000 CN.BS.PIN 8P
CB702 VQ585100 CN.BS.PIN 9P
CB711 VQ585100 CN.BS.PIN 9P
CB721 Vi879000 CN.BS.PIN 12P
CB722 Vi878600 CN.BS.PIN 8P
CB751 Vi878200 CN.BS.PIN 4P
CB761 Vi878200 CN.BS.PIN 4P
CB762 Vi878100 CN.BS.PIN 3P
C501 VJ599100 C.CE.TUBLR 0.1uF 50V
C502 VJ599100 C.CE.TUBLR 0.1uF 50V
C503 UR847100 C.EL 10uF 25V
C504 UR847100 C.EL 10uF 25V
C505 UR847100 C.EL 10uF 25V
C506 UR847100 C.EL 10uF 25V
C507 UR837470 C.EL 47uF 16V
C508 UR847100 C.EL 10uF 25V
C509 UR847100 C.EL 10uF 25V
C510 FG651330 C.CE 33pF 50V(RT)
C510 UA952220 C.MYLAR 220pF 50V(BG)
C511 VQ645600 C.MYLAR 100pF 50V
C512 FG651330 C.CE 33pF 50V(RT)
C512 UA952220 C.MYLAR 220pF 50V(BG)
C513 VQ645600 C.MYLAR 100pF 50V
C514 FG651330 C.CE 33pF 50V(RT)
C514 UA952220 C.MYLAR 220pF 50V(BG)
C515 UA952100 C.MYLAR 100pF 50V
C516 FG651330 C.CE 33pF 50V(RT)
C516 UA952220 C.MYLAR 220pF 50V(BG)
C517 UA952470 C.MYLAR 470pF 50V
C518 FG651330 C.CE 33pF 50V(RT)
C518 UA952220 C.MYLAR 220pF 50V(BG)
C519 UA952470 C.MYLAR 470pF 50V
C520 VQ245400 C.PP 33pF 200V
C521 UR838100 C.EL 100uF 16V
C522 UA953100 C.MYLAR 1000pF 50V
C523 VQ245400 C.PP 33pF 200V
C524 UR838100 C.EL 100uF 16V
C525 UA953100 C.MYLAR 1000pF 50V
C526 VQ245400 C.PP 33pF 200V
C527 UR837470 C.EL 47uF 16V
C528 UA953100 C.MYLAR 1000pF 50V
C529 VR516400 C.CE 15pF 500V
C530 UR837470 C.EL 47uF 16V
C531 UA953100 C.MYLAR 1000pF 50V
C532 VR516400 C.CE 15pF 500V
C533 UR837470 C.EL 47uF 16V
C534 UA953100 C.MYLAR 1000pF 50V
C535 UR867470 C.EL 47uF 50V
C536 UR867470 C.EL 47uF 50V
C537 UR867470 C.EL 47uF 50V
C538 UR867470 C.EL 47uF 50V
C539 UR867470 C.EL 47uF 50V
C540 VK347900 C.EL 470uF 63V
C541 VQ645600 C.MYLAR 100pF 50V
C542 VK399200 C.MYLAR.ML 0.39uF 50V
C543 UR867470 C.EL 47uF 50V
C544 VQ645600 C.MYLAR 100pF 50V
C545 VQ645600 C.MYLAR 100pF 50V
C546 VK399200 C.MYLAR.ML 0.39uF 50V
✻
✻
✻
✻
✻
