62
DSP-A595
Schm
Ref
PART NO. Description
✻ New Parts✻ New Parts
Schm
Ref
PART NO. Description
P. C. B. OPERATION
D801 VD631600 DIODE 1SS133,176,HSS104
D802 VM974100 DIODE.ZENR HZS5B2TD 5.0V
D803 VD631600 DIODE 1SS133,176,HSS104
D805 VD631600 DIODE 1SS133,176,HSS104
D806 VD631600 DIODE 1SS133,176,HSS104
D807 VM974100 DIODE.ZENR HZS5B2TD 5.0V
D808 VM974700 DIODE.ZENR HZS7B2TD 7.0V
D809 VD631600 DIODE 1SS133,176,HSS104
D811 VD631600 DIODE 1SS133,176,HSS104
D812 VM974400 DIODE.ZENR HZS6B2TD 6.0V(RT)
D812 VM974600 DIODE.ZENR HZS7A2TD 7.0V(BG)
D813 VM974500 DIODE.ZENR HZS6C2TD 6.0V
D814 VD631600 DIODE 1SS133,176,HSS104
D815 VR253700 DIODE.BRG S1NB20 1.0A 200V
D816 VM975300 DIODE.ZENR HZS11B2TD 11V(RT)
F800 KB000790 FUSE T4.0A 250V(RT)
F803 VT942900 FUSE TH2.5A 250V(G)
F804 KB000790 FUSE T4.0A 250V(BG)
F804 VS823300 FUSE T8.0A 125V(RT)
HS801 VR506800 HEAT.SINK PUH16-25(RT)
IC800 XU945J00 IC
LC876564A-5K19 CPU
IC801 XM356A00 IC NJM2068LD
IC802 XM356A00 IC NJM2068LD
JK800 V2589500 CN 1P
PJ800 VV852700 JACK.PIN 3P
Q800 VG721700 TR.DGT DTA144ES
Q801 iA093320 TR 2SA933S Q,R
Q802 iA093320 TR 2SA933S Q,R
Q803 VG722000 TR.DGT DTC144ES
Q805 iA093320 TR 2SA933S Q,R
Q806 VP872700 TR 2SC4488 S,T
Q807 iC174020 TR 2SC1740S R,S
Q808 VR510800 TR 2SD2396 J,K(RT)
Q810 iC287820 TR 2SC2878 A,B
Q811 iC287820 TR 2SC2878 A,B
R451 HV753100 R.CAR.FP 1Ω 1/4W
R452 HV753100 R.CAR.FP 1Ω 1/4W
R878 VP939800 R.MTL.OXD 10Ω 1W
R881 VP939800 R.MTL.OXD 10Ω 1W
R904 HV756560 R.CAR.FP 5.6KΩ 1/4W(RT)
R906 HV756560 R.CAR.FP 5.6KΩ 1/4W(RT)
RY800 V2712300 RELAY DC SDT-S-112LMR
SW800 VT140300 SW.RT.ENC EC16B12204
SW801 VG392900 SW.TACT SKHVAA
SW802 VG392900 SW.TACT SKHVAA
SW803 VG392900 SW.TACT SKHVAA
SW804 VG392900 SW.TACT SKHVAA
SW805 VG392900 SW.TACT SKHVAA
SW806 VG392900 SW.TACT SKHVAA
SW810 VG392900 SW.TACT SKHVAA
SW811 VG392900 SW.TACT SKHVAA
SW812 VG392900 SW.TACT SKHVAA
SW813 VG392900 SW.TACT SKHVAA
SW814 VG392900 SW.TACT SKHVAA
SW815 VG392900 SW.TACT SKHVAA
SW817 VG392900 SW.TACT SKHVAA
SW822 VG392900 SW.TACT SKHVAA
SW823 VG392900 SW.TACT SKHVAA
SW824 VG392900 SW.TACT SKHVAA
SW831 VA961800 VOLT.SELCT ESE-37247-F(RT)
T800 XC084A00 TRANS.PWR (BG)
T800 XT331A00 TRANS.PWR (RT)
TE800 VU543300 OUTLET.AC 1P(B)
TE800 VU543400 OUTLET.AC 2P(G)
TE800 VV118800 OUTLET.AC 3P(RT)
U800 VU591000 L.DTCT GP1U271X
V800 V2421800 FL.DSPLY 16-BT-59GK
VR800 VP741800 VR B20KΩ
VR801 VP741900 VR G25KΩ
VR802 VP742000 VR MN100KΩ
XL800 VQ791000 RSNR.CE 10MHz
BB071360 SCR.TERM 8.3x13
VS588900 SHEET
V3422300 SPACER FL-WIDE
EP600140 SCR.BND.HD 3x10 MFZN2-BL(RT)
!
!
!
!
!
✻
!
!
!
!
!
✻
