Specifications
Audio Section
Minimum RMS Output Power
20 Hz to 20 kHz, 0.02% THD, 8 ohms
Main L/R, Center, Rear L/R, Rear Center......................100 W
1 kHz, 0.05% THD
Front L/R ..........................................................................25 W
<General and China models>
Maximum Output Power (EIAJ)
1 kHz, 10% THD, 8 ohms
Main L/R, Center, Rear L/R, Rear Center......................135 W
Front L/R ..........................................................................35 W
DIN Standard Output Power
1 kHz, 0.7% THD, 4 ohms, Main L/R ................................160 W
IEC Output Power
1 kHz, 0.015% THD, 8 ohms, Main L/R ............................115 W
Dynamic Power (IHF)
8/6/4/2 ohms, Main L/R ................................ 140/170/220/320 W
Damping Factor
20 Hz to 20 kHz, 8 ohms, Main L/R .......................... 200 or more
Power Band Width
50 W, 0.08% THD, 8 ohms, Main L/R ............... 10 Hz to 50 kHz
Frequency Response
CD to Main L/R..................................... 10 Hz to 100 kHz, –3 dB
Total Harmonic Distortion
20 Hz to 20 kHz, 50 W, 8 ohms, Main L/R ...................... 0.015%
Signal to Noise Ratio (IHF-A Network)
CD (250 mV input shorted) to Main L/R, Effect Off.........100 dB
PHONO (5 mV input shorted) to Main L/R, Effect Off ......86 dB
Residual Noise (IHF-A Network)
Main L/R ................................................................ 150 µV or less
Channel Separation (1 kHz/10 kHz)
CD (5.1k terminated) to Main L/R ............................ 60 dB/45 dB
Tone Control (Main L/R)
BASS Boost/Cut ...................................................... ±10 dB/50 Hz
TREBLE Boost/Cut...............................................±10 dB/20 kHz
Bass Extension ..........................................................+6 dB/60 Hz
Phones Output .......................................................150 mV/100 ohms
Input Sensitivity
CD etc. ..............................................................150 mV/47 kohms
Phono .................................................................2.5 mV/47 kohms
Main In ....................................................................1 V/47 kohms
Output Level
REC OUT ...........................................................150 mV/1 kohms
PRE OUT ...............................................................1 V/1.2 kohms
SUB WOOFER ......................................................4 V/1.2 kohms
Video Section
Video Signal Type ....................................................................... PAL
[China and General models] ....................................... NTSC/PAL
Composite Video Signal Level................................. 1 Vp-p/75 ohms
S-Video Signal Level
Y .......................................................................... 1 Vp-p/75 ohms
C ................................................................... 0.286 Vp-p/75 ohms
Component Video Signal Level
Y .......................................................................... 1 Vp-p/75 ohms
P
B/CB, PR/CR ................................................................................. 0.7 Vp-p/75 ohms
Signal to Noise Ratio.................................................................50 dB
Frequency Response (MONITOR OUT)
Composite, S-Video ..................................5 Hz to 10 MHz –3 dB
Component ..................................................DC to 30 MHz –3 dB
General
Power Supply
[Europe and U.K. models] .................................. AC 230 V/50 Hz
[China and General models] .... AC 110/120/220/240 V, 50/60 Hz
Power Consumption .................................................................480 W
Standby Mode.......................................................................1.2 W
AC Outlets (Total 100 W maximum) ............................. 3 (Switched)
[U.K. model].............................................................. 1 (Switched)
Dimension (W x H x D)
...................... 449 x 191 x 468 mm (17-5/8" x 7-1/2" x 18-7/16")
Weight ....................................................................... 22 kg (48.5 lbs)
Accessories ................................................................Remote Control
Batteries
Quick Reference Guide
Side Panel Sticker
[Europe model] ...................................................... Power Cord
* Specifications are subject to change without notice.
