■ SPECIFICATIONS/参考仕様
■ Audio Section / オーディオ部
Minimum RMS Output Power (Power Amp. Section) /
定格出力(パワーアンプ部)
[RX-V661/DSP-AX761] (20 Hz to 20 kHz)
U, C, R, T, K, A, B, G, E, L models (0.06 % THD, 8 ohms)
J model (0.09 % THD, 6 ohms)
FRONT L/R............................................................. 90 W + 90 W
CENTER ............................................................................. 90 W
SURROUND L/R ....................................................90 W + 90 W
SURROUND BACK L/R .........................................90 W + 90 W
[HTR-6060] (1 kHz, 0.7 % THD, 8 ohms)
FRONT L/R........................................................ 105 W + 105 W
CENTER ........................................................................... 105 W
SURROUND L/R ............................................... 105 W + 105 W
SURROUND BACK L/R .....................................105 W + 105 W
Maximum Power / 実用最大出力 (JEITA, 1 kHz, 10 % THD)
FRONT L/R
R, T, K, L models (8 ohms) .................................. 130 W + 130 W
J model (6 ohms) ................................................. 130 W + 130 W
CENTER
R, T, K, L models (8 ohms) ................................................. 130 W
J model (6 ohms) ................................................................ 130 W
SURROUND L/R
R, T, K, L models (8 ohms) .................................. 130 W + 130 W
J model (6 ohms) ................................................. 130 W + 130 W
SURROUND BACK L/R
R, T, K, L models (8 ohms) .................................. 130 W + 130 W
J model (6 ohms) ................................................. 130 W + 130 W
Max. Power Per Channel/Max.パワー
(SP impedance set: 8 ohms minimum, 1 kHz, 0.7 % THD, 4 ohms)
B, G, E, L models
FRONT L/R .......................................................... 140 W + 140 W
CENTER.............................................................................. 140 W
SURROUND L/R .................................................. 140 W + 140 W
SURROUND BACK L/R ........................................ 140 W + 140 W
IEC Power / IECパワー (1 kHz, 0.06 % THD, 8 ohms)
B, G, E, L models
FRONT L/R .......................................................... 100 W + 100 W
Dynamic Power Per Channel / ダイナミックパワー (IHF)
FRONT L/R (8/6/4/2 ohms)
U, C, R, T, K, A, B, G, E, L models ............... 120/155/190/235 W
J model ............................................................... –/130/160/205 W
Dynamic Headroom / ダイナミックヘッドルーム
U, C models (8 ohms)............................................................ 1.4 dB
Damping Factor / ダンピングファクタ
FRONT L/R ( 20 Hz to 20 kHz, SPEAKER-A, 8 ohms ) ...... 120 or more
Input Sensitivity/Input Impedance / 入力感度/入力インピーダンス
(1 kHz, 100 W/8 ohms)
PHONO (MM) ................................................... 3.5 mV / 47 k-ohms
CD, etc. ............................................................ 200 mV / 47 k-ohms
MULTI CH INPUT
FRONT L/R, CENTER, SURROUND L/R, SURROUND BACK L/R,
SUBWOOFER
.................................................................... 200 mV / 47 k-ohms
Maximum Input Signal Level / 最大許容入力
PHONO (MM) (1 kHz, 0.1 % THD) .......................... 60 mV or more
CD, etc. (Effect on) (1 kHz, 0.5 % THD) ....................2.3 V or more
Output Level/Output Impedance / 出力電圧/出力インピーダンス
REC OUT ........................................................ 200 mV / 1.2 k-ohms
PRE OUT (FRONT L/R, CENTER, SURROUND L/R,
SURROUND BACK L/R).................................. 1.0 V / 1.2 k-ohms
SUBWOOFER (2ch stereo & FRONT L/R SP: small)
.......................................................................... 1.0 V / 1.2 k-ohms
[RX-V661 (U, C, R, T, K, A, G, E, L models)/HTR-6060 (G model)]
ZONE2 OUT ................................................. 200 mV / 1.2 k-ohms
Headphone Jack Rated Output/Impedance / ヘッドフォン出力/出
力インピーダンス
CD, etc. (1 kHz, 50 mV, 8 ohms) ..................... 150 mV / 100 ohms
Frequency Response / 周波数特性 (10 Hz to 100 kHz)
CD, etc. to FRONT L/R (Pure direct) .............................. +0/-3.0 dB
RIAA Equalization Deviation / RIAA偏差 (20 Hz to 20 kHz)
PHONO (MM) .................................................................. 0 ± 0.5 dB
Total Harmonic Distortion / 全高調波歪率(20 Hz to 20 kHz)
PHONO (MM) to REC OUT (1 V) .............................. 0.02 % or less
CD, etc. (2ch stereo) to FRONT L/R SP OUT (50 W, 8 ohms)
.................................................................................0.06 % or less
Signal to Noise Ratio / 信号対雑音比 (IHF-A network)
PHONO (MM) (Input shorted) to REC OUT
U, C, R, T models (5 mV) ....................................... 86 dB or more
K, A, B, G, E, L models (5 mV) ...............................81 dB or more
J model (2.5 mV) .....................................................80 dB or more
CD, etc. (Effect off) (Input shorted) to SP OUT
250 mV ..................................................................100 dB or more
Residual Noise / 残留ノイズ (IHF-A network)
FRONT L/R, SP OUT ............................................... 150 µV or less
Channel Separation / チャンネルセパレーション (1 kHz/10 kHz)
PHONO (Input shorted) .................... 60 dB or more/55 dB or more
CD, etc. (
Input 5.1 k-ohms shorted ) ..... 60 dB or more/45 dB or more
Volume Control / 可変範囲/ステップ
............................................ MUTE/-80 dB to +16.5 dB/0.5 dB step
Tone Control Characteristics / トーンコントロール特性
BASS
Boost/Cut ............................................ ± 10 dB/2 dB (step 50 Hz)
Turnover frequency ............................................................ 350 Hz
TREBLE
Boost/Cut ......................................... ± 10 dB/2 dB (step 20 k-Hz)
Turnover frequency ........................................................... 3.5 kHz
Filter Characteristics / フィルター特性
(fc=40/60/80/90/100/110/120/160/200 Hz)
FRONT, CENTER, SURROUND, SURROUND BACK small
(H.P.F.) .......................................................................... 12 dB/oct.
SUBWOOFER (L.P.F.) .................................................... 24 dB/oct.
■ Video Section / ビデオ部
Video Signal Type / ビデオ信号方式
Gray back
U, C, R, K, J models ............................................................ NTSC
T, A, B, G, E, L models ........................................................... PAL
Video conversion ............................................................ NTSC/PAL
Composite Video Signal Level / コンポジットビデオ信号
.............................................................................. 1 Vp-p / 75 ohms
S-Video Signal Level / Sビデオ信号
Y ............................................................................ 1 Vp-p / 75 ohms
C ..................................................................... 0.286 Vp-p / 75 ohms
Component Video Signal Level / コンポーネントビデオ信号
Y ............................................................................ 1 Vp-p / 75 ohms
Cb/Cr .................................................................. 0.7 Vp-p / 75 ohms
D4-Video Signal Level / D4ビデオ信号 (J model)
Y ............................................................................ 1 Vp-p / 75 ohms
Cb/Cr .................................................................. 0.7 Vp-p / 75 ohms
Video Maximum Input Level / ビデオ最大許容入力
VIDEO CONV. OFF .............................................. 1.5 Vp-p or more
Video Signal to Noise Ratio / ビデオ信号対雑音比
VIDEO CONV. OFF ................................................... 50 dB or more
Monitor Out Frequency Response / モニターアウト周波数帯域
(VIDEO CONV. OFF)
Component video signal level ...................... 5 Hz to 60 MHz, -3 dB
D4-video signal level (J model) .................... 5 Hz to 60 MHz, -3 dB
■ FM Section / FM部
Tuning Range / 受信周波数範囲
U, C models ........................................................ 87.5 to 107.9 MHz
R, L models ............................ 87.5 to 108.0 / 87.50 to 108.00 MHz
T, K, A, G, E models ....................................... 87.50 to 108.00 MHz
J model ................................................................. 76.0 to 90.0 MHz
50dB Quieting Sensitivity / 50dBSN感度 (IHF, 1 kHz, 100 % MOD.)
Mono ..................................................................... 2.8 µV (20.2 dBf)
Signal to Noise Ratio / 信号対雑音比 (IHF)
Mono / Stereo ............................................................. 73 dB / 70 dB
Harmonic Distortion / 歪率 (1 kHz)
Mono / Stereo ............................................................. 0.5 % / 0.5 %
Antenna Input / アンテナ入力 ......................... 75 ohms unbalanced
■ AM Section / AM部
Tuning Range / 受信周波数範囲
U, C models .......................................................... 530 to 1,710 kHz
R, L models ................................... 530 to 1,710 / 531 to 1,611 kHz
T, K, A, G, E, J models ......................................... 531 to 1,611 kHz
Antenna Input / アンテナ入力 .................................... Loop antenna
