42
RX-V661/HTR-6060/DSP-AX761
RX-V661/HTR-6060/
DSP-AX761
Display / 表示
0 - 4
5 - 13
14 - 21
22 - 31
32 - 42
43 - 53
54 - 61
62 - 68
69 - 75
76 - 82
83 - 89
90 - 100
KEY0
MAIN ZONE ON/OFF
SCENE1
SCENE2
–
–
STRAIGHT
TONE CONTROL
SEARCH MODE /EDIT
–
SPEAKERS
PURE DIRECT
KEY OFF
Zone2 ON/OFF
SCENE3
SCENE4
ZONE CONTROL
AUDIO SELECT
FM/AM
A/B/C/D/E
PRESET <
PRESET >
MEMORY
DISPLAY
KEY OFF
KEY1
K0:100 K1:100
K0/K1
K0/K1： KEY0/KEY1（本機パネルキー）
キーのA/D値は基準値から外れると、正常な
動きをしません。
下表をご覧になり、各キーの分圧抵抗の定
数、ハンダ不良等の確認をしてください。
（基準電圧：5.0V＝100）
K0/K1
K0/K1: KEY0/KEY1(Panelkeyofmainunit)
A/Dvalueofthekeyfailstofunctionproperly
whenthestandardvalueisdeviated.
Inthiscase,checktheconstantofpartial
pressureresistor,soldercondition,etc.
Refertotable.
(Referencevoltage:5.0V=100)
PLDET (8-ohm/6-ohm)
LIM (Limiter control)
U, C, T, K, A, B, G, E models (Reference voltage: 5.0 V=255)
During normal operation
255 / 255
H
Value for starting limiter operation
87 / 146
L
Value for canceling limiter operation
125 / 171
H
PLDET (8-ohm/6-ohm)
LIM (Limiter control)
R, L models (Reference voltage: 5.0 V=255)
During normal operation
255 / 255
H
Value for starting limiter operation
100
L
Value for canceling limiter operation
131
H
PLDET（8-ohm/6-ohm）
LIM（リミッター制御）
Jmodel（基準電圧：5.0V＝255）
通常値
255/255
H
リミッタ動作開始値
100
L
リミッタ動作解除値
131
H
RX-V661 (U, C, R, T, K, A, G, E, L models)/HTR-6060 (G model)
Display / 表示
0 - 4
5 - 13
14 - 21
22 - 31
32 - 42
43 - 53
54 - 61
62 - 68
69 - 75
76 - 82
83 - 89
90 - 100
KEY0
–
SCENE1
SCENE2
–
–
STRAIGHT
TONE CONTROL
SEARCH MODE /EDIT
–
SPEAKERS
PURE DIRECT
KEY OFF
NIGHT
SCENE3
SCENE4
SLEEP
AUDIO SELECT
FM/AM
A/B/C/D/E
PRESET <
PRESET >
MEMORY
DISPLAY
KEY OFF
KEY1
HTR-6060 (U, C models)/DSP-AX761 (J model)
Display / 表示
0 - 4
5 - 13
14 - 21
22 - 31
32 - 42
43 - 53
54 - 61
62 - 68
69 - 75
76 - 82
83 - 89
90 - 100
KEY0
–
SCENE1
SCENE2
–
–
STRAIGHT
TONE CONTROL
–
–
SPEAKERS
PURE DIRECT
KEY OFF
–
SCENE3
SCENE4
–
AUDIO SELECT
–
–
–
–
–
–
KEY OFF
KEY1
DSP-AX761 (B model)
