E
2-11
R
N
F
q
w
e
r
t
y
u
u
t
r
y
701031
702032
q
w
e
rr
tty
y
u
u
000323
UP
DN
N
000324
q
w
EMU00098
Remote Control Lever
Moving the lever forward from the Neutral
position engages Forward gear. Pulling the
lever back from Neutral engages Reverse.
The engine will continue to run at idle until
the lever is moved about 35° (a detent can
be felt). Moving the lever farther opens the
throttle, and the engine will begin to accel-
erate.
1 Neutral
2 Forward
3 Reverse
4 Shift
5 Fully closed
6 Throttle
7 Fully open
EMU00099
Neutral Interlock Trigger
To shift out of Neutral, the neutral interlock
trigger of the remote control lever must first
be pulled up.
EMU00100
Neutral Throttle Lever
To open the throttle without shifting into
either Forward or Reverse, place the
remote control lever in the Neutral position
and lift the neutral throttle lever.
NOTE:
The neutral throttle lever will operate only
when the remote control lever is in Neutral.
The remote control lever will operate only
when the neutral throttle lever is in the
closed position.
1 Fully open
2 Fully closed
