2-12
E
ON
STARTOFF
ON
STARTOFF
001242
701055
ON
STARTOFF
703031
EMU00101
Main switch
The main switch controls the ignition sys-
tem; its operation is described below.
8 OFF
Electrical circuits switched off.
(The key can be removed.)
8 ON
Electrical circuits switched on.
(The key cannot be removed.)
8 START
Starter-motor will turn and start engine.
(When the key is released, it returns auto-
matically to “ON”.)
EMU00102
Choke Switch
While the main switch is being pressed in at
“ON” or “START”, the choke system will
switch on, to supply a rich mixture required
to start the engine. (When the key is
released, it will switch off automatically.)
60H-9-E1-2 3/1/02 9:36 PM Page 13
