2-9
E
EMU01563
POWER TRIM/TILT SWITCH
The power trim/tilt adjusts the motor angle in
relation to the transom. The power trim/tilt
switch is located on the side of the bottom
engine cowling. Pushing the switch “UP”
trims the motor up, then tilts the motor up.
Pressing the switch “DN” tilts the motor
down and trims the motor down. When the
switch button is released, the motor will stop
in its current position.
WARNING
@ @
Use the power trim/tilt switch located on
the bottom engine cowling only when the
boat is at a complete stop with the
engine off. Attempting to use the cowl-
ing-mounted power trim/tilt switch while
the boat is moving could increase the
risk of falling overboard and could dis-
tract the operator, increasing the risk of
collision with another boat or an obsta-
cle.
@
NOTE:
@
Refer to the sections “ADJUSTING TRIM
ANGLE” and “TILTING UP/DOWN” for
instructions on usage.
@
