2-13
E
EMU00140
DIGITAL SPEEDOMETER
This meter contains the speedometer, fuel
meter with warning, trip meter, clock and
voltmeter with warning.
1
Speedometer
2
Fuel meter
3
Trip meter/clock/voltmeter
4
Warning indicator
NOTE:
@
After the main switch is first turned on, all
portions of the meter come on as a check.
After a few seconds, the meters will change
to normal operation. Watch the meter when
turning on the main switch to make sure all
segments come on.
@
EMU00141
Speedometer
This meter shows the boat speed.
NOTE:
@
The speedometer displays km/h, mph, or
knots, depending upon operator preference.
Select the desired unit of measurement by
setting the selector switch on the back of the
meter. See the illustration for settings.
@
1
Cap
2
Selector switch (for speed unit)
3
Selector switch (for fuel sender)
E_69J10.book Page 13 Monday, May 28, 2001 9:52 AM
